Infinity 6100M - Applications; 6100 M System Speaker-Level Connection; 6100 M System Line-Level Connection

Remote
Turn-On
L Speaker
Source Unit
Splices
(not supplied)
Splices
(not supplied)
R Speaker
LF Speaker
Remote
Turn-On
LR Speaker
Source Unit
RF Speaker
RR Speaker
APPLICATIONS
6
Figure 12. 6100m System speaker-level connection.
Figure 13. 6100m System line-level connection.
