2
Figure 1. Drawing shows assembly procedure (ERS 840 is shown).
Planning the Installation
When surveying potential installation sites for ERS Series
speakers, keep the following points in mind:
• Allow at least a two-inch clearance in all directions behind the
wallboard. The assembly is designed for easy horizontal or
vertical mounting between wall studs.
NOTE: Due to its size, the ERS 840 can only be mounted vertically.
It will not fit horizontally between standard 16" stud-centers.
• For the best stereo image, position the speakers not less than
seven to ten feet apart.
