Part Number Qty
Reference Designator
Description
Main PCB
Capacitors
06D341047400 Capacitor 104/100V ±5% 5MM 2 C125E C126E
06D374717400 Capacitor 470pF/100V ±5% 5.5mm 1 C122E
06D232227001 Capacitor 222/100 ±20% 5mm 2 C128L C33
06D231047000 Capacitor 0.1uF/100V ±20% 5MM 3 CC8 C128P C128W
06D322227200 Capacitor 222/100V ±5% 5MM 1 C117E
06D321027200 Capacitor 102/100V ±5% 5MM 2 C150P C152P
06D341037400 Capacitor 103/100V ±5% 5MM 4 CC2 CC44 CC5 CC3
06D1C104C700 Capacitor 104/250V ±10%，CBB，，10MM， 1 C14
06D1C105G701 Capacitor 105/160V ±10%，CBB，11.5*8.5*15.5MM,10.5MM, 2 C12 C115E
06D2C106G70
Capacitor 106/160V 20MM 105℃ ±20% 2 C123E C124E
06D2C3357700 Capacitor 3.3UF/100V ±20% 105℃ 20.5mm 1 C121E
06D3C1059700 Capacitor 105/63V ±5% 5MM MAX:10.5MM*10.5MM*6.0MM 4 C111P C113P C116E C119E
06D212256104 Capacitor 2.2uF/50V ±20% 4*7 105℃ 3 C173P CC4 C143
06D212273100 Capacitor 220UF/16V ±20% 6.3*7 2 CA123P CA124P
06D212275101 Capacitor 220UF/35V ±20% 8*14 105℃ 5mm 1 C142P
06D212274001 Capacitor 220UF/25V ±20% 8*16 105℃ 5mm 6 C601 C501 C401 C201 C101 C301
06D151073100 Capacitor 100UF/16V ±10% 6*5 105℃ 1 C142PD
06D211074111 Capacitor 100uF/25V ±20% 6.3*11 105℃ 2.5MM 8
C112E C114E C153P C155P C157P CA153P
CA248E CC11
06D211064000 Capacitor 10UF/25V ±20% 4*7 105℃ 2.5MM 28
C107 C108 C207 C208 C307 C308 C407 C408
C702 C703 C503 C203 C202 C502 C403 C402
C303 C302 C102 C103 C602 C603 C106D C106C
C106A C106B C127E C110
06D213366102 Capacitor 33UF/50V ±20% 5*11 105℃ 5MM 1 C502G
06D214765167 Capacitor 47UF/35V ±20% 6.3*7 105℃ 5MM 3 C154P C11 C9
06D213384013 Capacitor 3300UF/25V ±20% Φ13*28MM 105℃ ≤28MM 3 C137P C139P C138P
06D214784016 Capacitor 4700UF/25V ±20% Φ16*28MM 105℃ ≤28MM 1 C136P
06D213389025 Capacitor 3300UF/63V ±20% Φ25*28MM 105℃ ≤28MM 2 C172P C171P
06D213385018 Capacitor 3300UF/35V ±20% Φ18*28MM 105℃ ≤28MM 2 C163P C162P
06D203364000 Capacitor 33uF/25V 6.3*7 ±20% 105℃ 2 C105E C109
06D214764102 Capacitor 47uF/25V ±20% 5*11 105℃ 5MM 1 C142G
06S121017000 Capacitor SMD 100PF/100V 0805 X7R ±10% 7 C001 C002 C003 C004 C005 C006 C309
06S321026000 Capacitor SMD 1000pF/50V 0805 NPO ±5% 4 C105A C105B C105C C105D
06S121047001 Capacitor SMD 104/100V ±10% X7R 0805 TDK 40
C1 C3 C5 C7 C8 C10 C18 C19 C20 C24 C25 C26
C27 C28 C29 C30 C120P C125P C129PB
C130PB C131PB C132PB C140P C167G C167P
C168G C169P C170P C509S C609S C709S
C809S CA3 CA7 CA125P CA126P CA126PA
C113E C104E C166PS
06S13104C001 Capacitor SMD 104/250V ±10% X7R 1206 TDK 1 C127P
06S321006000 Capacitor SMD 10pF/50V 0805 NPO ±5% 7 C704 C504 C604 C404 C304 C104 C204
06S123326000 Capacitor SMD 332/50V ±10% X7R 0805 6 C104A C104B C104C C104D C104F C108P
06S122246002 Capacitor SMD 224/50V ±10% X7R 0805 TDK 7 CC10 CC9 CC7 CC6 CC1 C105P CA8
06S124727000 Capacitor SMD 472/100V 0805 X7R ±10% 6 C1A C3A C21 C22 C23 C34
06S124736000 Capacitor SMD 0.047uF/50V 0805 X7R ±10% 2 C2A C4A
06S322206000 Capacitor SMD 22pF/50V 0805 NPO ±5% 14
C506 C505 C605 C606 C406 C405 C306 C206
C106 C105 C205 C305 C116A C116C
06S132256000 Capacitor SMD 2.2uF/50V 1206 X7R ±10% 3 C6A C501G C100
Semiconductors
04ZL-5404-06 Diode ASC SPA 1N5404 DO-201AD 3A 400V 52MM 1 D1
03P1-A940-02 Transistor 2SA940 PNP TO-220 1 Q202
03N1-2073-02 Transistor 2SC2073 NPN TO-220 1 Q201
03N1-P31C-02 Transistor TIP31C TO-220 NPN 1 QA1
03T1-K117-01 FET 2SK117BL TO-92 N channel 5 Q107E Q100A Q100B Q100C Q100D
03N1-669A-07 Transistor 2SD669A NPN TO-126 1 QA109E
03T2-7805-01 Regulator 78L05 TO-92 5V/100MA 2 U107 U102E
0100-9L05-03 Regulator 79L05 TO-92 5V/100MA 2 U108 U103E
01NS-M317-04 Regulator VREG ADJ 1.2-37V 1.5 AMP TO-220 LM317 1 U102P
03D1-38N2-02 Mos Fet IRFB 38N20D TO-220 4 Q100E Q101E Q102E Q103E
KAPPA FIVE
