Part Number Qty
Reference Designator
Description
Main PCB
03T1-Z48V-02 Mos Fet IRFZ 48V TO-220 8
Q113P Q114P Q116P Q117P Q118P Q119P
Q120P Q115P
04WY-12BV101 Zener Diode SMD 12V DO-213AA 0.5W 5 ZA102P D502S D602S D702S D802S
04WY-15BV111 Zener Diode SMD 15V SOD-123 0.5W 3 ZD102P ZD103P ZDA1
04WY-56AV101 Zener Diode SMD 5.6V DO-213AA 0.5W 1 ZD201E
04ZL-4007-02 Diode SMD FM4007 DO-214AC 1 D110E
04PT-4148-11 Diode SMD 1N4148 SOD-123 20
D2 D3 D5 D101E D102E D104 D104E D105
D101P D105E D106E D107E D111E D116P
D501S D601S D701S D801S D112E D4
04ZL-2512-00 Diode SMD MUR120 1A 2512 12
D101A D101B D101C D101D D102A D102B
D102C D102D D108E D109E D103S D121P
03P1-5401-04 Transistor SMD MMBT5401LT1 PNP SOT-23 3 Q106E Q502G Q102PA
03N1-5551-04 Transistor SMD MMBT5551LT1 NPN SOT-23 10
Q104PD Q10 Q103 Q104E Q105E QA209E
Q103PD Q123P Q501G Q10G
03N1-1815-04 Transistor SMD 2SC1815 SOT-23 NPN 4 Q103S Q102P Q103G Q103P
03P1-2907-04 Transistor SMD BT2907 SOT-23 PNP 1 Q210
01JR-4560-08 Dual Op-amp SMD 4560 SOP-8 JRC 7 U103A U501 U201 U101 U103 U105 U106
01ST-L074-08 Quad Op-amp SMD TL074 SOP-14 1 U102
03N1-XN15-03 Dual Transistor SMD XNO1215 NPN SC-74J 4 U502S U602S U702S U802S
0100-NE55-08 Timer SMD NE555 SOP-8 2 U1 U502
0100-IRF7-08 Mos Fet SMD IRF7341 SOP-8 4 U501S U601S U701S U801S
2202-1602-05 Dual Diode DIP UF1602CT AKA 16/200V TO-220 2 D117P D118P
2202-20RG-05 Dual Diode DIP MUR1620RG KAK 16A/200V TO-220 ON SEMI 2 D119P D120P
Miscellaneous
1001-2002-10 Inductor DIP 20uH Φ25*26MM T106-2 1 L101E
1001-4001-10 Inductor DIP 40uH Φ31*28MM T130-2 Φ1.6 1 L100E
1004-0005-10 Inductor W5 RH 3.5*8*0.8-2 8 L14 L15 L16 L17 L18 L19 L20 R1
1004-0004-10 Inductor DIP 3.5MM/L=5MM 0Ω 7.5MM 2 L24 L23
1501-0809-0A pin holder DIP 8P PITCH2.54MM 2 J2A J1A
1501-1209-08 pin holder DIP 12P PITCH2.54MM 2 CON3A CON2A
1501-0409-04 pin holder DIP 4P PITCH2.54MM 2 J3A J4A
1505-0609-01 pin holder DIP 2*6P PITCH2.54MM*2.54MM 1 CON1A
1401-0008-00 Fuse Holder DIP 2PIN BXS2-09 1 for F101P
1601-403G-01 Fuse DIP 40A/32V UL Littelfuse 4 F101P
1380-0209-00
Temperature switch
DIP80℃±5℃ TO-220 2PCS 1 TH351
1500-1012-B1 Terminal 10P JSZ10-26A SPEAKER TERMINAL 1 J1
1501-0300-04 Terminal DIP JS23A-25A 3PIN POWER TERMINAL 1 J102P
1332-0206-00 Switch SK-22H07AG6 SW2P2T-SD INT/EXT 4CHAN/2CHAN 2 SW100E SW100R
24D1-0055191 Grounding cable 1015#18AWG L=55MM 4.2 3 EA1 EA2 EA3
1404-0020-04 QUAD RCA AV4-8.4-38 QUAD JACK MAIN INPUTS 1 RCA1
3000-KAPP-02 Transformer Φ37 5.5:10.5(Φ0.8*8P:Φ0.8*4P) 1 T100P
3000-KAPP-03 Transformer Φ37 4.5:16.5:6(Φ0.8*8P:Φ0.8*4P:Φ1.0*1P) 1 T101P
1001-4501-10 Inductor Φ0.9*4P K6A Φ16*6 45UH 2 L108 L107
1001-3003-10 Inductor Φ0.8*3P K6A Φ13*6 30UH 2 LL1 LL3
1001-3004-10 Inductor Φ0.65*4P K6A Φ13*6 30UH 3 L106 L104 L105
2901-0000-00 Relay 12A/120VAC 12VDC 20.5*16.5*20.2MM 1 J1E
1001-1301-10 Inductor Φ28*12MM(Φ1.0*6P)*2+1.0*1P K5A 13UH 7.5UH 1 L101
1501-0300-05 Terminal 3P JSZ3-83 180 1
1404-0027-02 DUAL RCA AV2-8.4-38 DUAL JACK SUB INPUTS 1 SUB
2102-0058-05 FFC 5Pin 2.0 UL1517 28AWG L=65MM 1 CON201A
1400-0011-08 RJ45 RJ45-10P8C 8PIN IMS INPUT 1 RJ45
Control/Preamp/PWM PCB
Resistors
0701-2000-02 Resistor SMD 0Ω 1/8W ±5% 0805 1 R201E
0701-34R7-04 Resistor SMD 4.7Ω 1/10W ±5% 1206 3 R43 R42 R21
0701-2100-02 Resistor SMD 10Ω 1/8W ±5% 0805 2 R23 R23A
0701-2101-02 Resistor SMD 100Ω 1/8W ±5% 0805 1 R39
0701-2221-02 Resistor SMD 220Ω 1/8W ±5% 0805 1 R112E
KAPPA FIVE
