Infinity KAPPA FIVE - Page 13

Part Number Qty
Reference Designator
Description
Control/Preamp/PWM PCB
0701-2331-02 Resistor SMD 330Ω 1/8W ±5% 0805 3 R46 R206E R215E
0701-2681-02 Resistor SMD 680Ω 1/8W ±5% 0805 7 R101E R101A R101B R101D R101C R32 R32A
0701-2182-02 Resistor SMD 1.8KΩ 1/8W ±5% 0805 1 R114E
0701-2222-02 Resistor SMD 2.2KΩ 1/8W ±5% 0805 2 R27 R28
0701-2472-03 Resistor SMD 4.7KΩ 1/8W ±1% 0805 11
R108E R109E R22 R38 R60 R106A R106B
R106C R106D R106E R204E
0701-2512-02 Resistor SMD 5.1KΩ 1/8W ±5% 0805 1 R217E
0701-2752-02 Resistor SMD 7.5KΩ 1/8W ±5% 0805 8
R108B R108C R108D R109B R108A R109A
R109C R109D
0701-2822-02 Resistor SMD 8.2KΩ 1/8W ±5% 0805 4 R105A R105B R105C R105D
07012909XK03 Resistor SMD 9.09KΩ 1/8W 0805 ±1% 16
R100B R104B R103B R102B R104A R103A
R102A R100A R104D R104C R103D R103C
R102D R102C R100D R100C
0701-2103-03 Resistor SMD 10K 1/8W ±1% 0805 5 R41 R115E R116E R202E R40
0701-2123-02 Resistor SMD 12KΩ 1/8W ±5% 0805 1 R47
0701-2183-03 Resistor SMD 18KΩ 1/8W ±1% 0805 1 R113E
0701-2273-03 Resistor SMD 27KΩ 1/8W ±1% 0805 1 R210E
0701-2363-02 Resistor SMD 36K 1/8W ±5% 0805 1 R103E
0701-2433-02 Resistor SMD 43K 1/8W ±5% 0805 2 R211E R216E
0701-2473-02 Resistor SMD 47KΩ 1/8W ±5% 0805 1 R205
0701-2105-02 Resistor SMD 1MΩ 1/8W ±5% 0805 1 R220E
0701-2202-02 Resistor SMD R0805 2KΩ 1/8W ±5% 4 R208E R209E R212E R214E
0701-1102-02 Resistor SMD 1KΩ 1/10W ±5% 0603 2 R40L R41L
0701-1222-02 Resistor SMD 2.2KΩ 1/10W ±5% 0603 1 R29
0701-1302-02 Resistor SMD 3KΩ 1/10W ±5% 0603 1 R24L
0701-1442-03 Resistor 4.42KΩ 1/10W ±1% 0603 SMD 1 R35
0701-1562-02 Resistor SMD 5.6KΩ 1/10W ±5% 0603 1 R26
0701-1103-02 Resistor SMD 10KΩ 1/10W ±5% 0603 5 R33 R10 R23L R22L RR
0701-1153-02 Resistor SMD 15KΩ 1/10W ±5% 0603 2 R19 R25
0701-1183-02 Resistor SMD 18KΩ 1/10W ±5% 0603 1 R14
0701-1223-02 Resistor SMD 22KΩ 1/10W ±5% 0603 1 R37
0701-1473-02 Resistor SMD 47KΩ 1/10W ±5% 0603 1 R30
0701-1104-02 Resistor SMD 100KΩ 1/10W ±5% 0603 6 R13 R36 R107A R107B R107C R107D
0701-1472-02 Resistor SMD 4.7KΩ 1/10W ±5% 0603 1 R21L
0701-2102-02 Resistor SMD 1KΩ 1/8W ±5% 0805 3 R100E R102E R203E
0701-2104-02 Resistor SMD 100KΩ 1/8W ±5% 0805 1 R24
1204-2041-04 Variable Resistor
B200K/B2K L=20 R1=B200K/R2=B2K ±15% SUB HP FREQ
1 VR103E
1204-2031-33 Variable Resistor B20K L=20 ±10% REAR, FRONT LEVEL 2 VR100C VR100A
1203-2031-17 Variable Resistor B20K L=20 ±10% SUB LEVEL 1 VR102E
1203-5011-03 Variable Resistor B500Ω L=20 ±10% BOOST 1 VR101E
1204-5031-37 Variable Resistor C50K L=20 ±10% REAR, FRONT FREQ 2 VR101C VR101A
1204-5031-36 Variable Resistor C50K L=20 ±10% LP FREQ 1 VR100E
Capacitors
06D214763104 Capacitor 47uF/16V ±20% 4*7 105℃ 1 C201E
06D321027200 Capacitor 102/100V ±5% 5MM 1 C26
06D341047400 Capacitor 104/100V ±5% 5MM 4 C105A C105B C105C C105D
06D344727400 Capacitor 472/100V ±5% 5MM 2 C36 C37
06D341847000 Capacitor 184/100V ±5% 5MM 1 C107E
06D942747400 Capacitor 274/100V ±2% 5MM 1 C109E
06D344737400 Capacitor 473/100V ±5% 5MM 4 C104A C104B C104C C104D
06D346837400 Capacitor 683/100V ±5% 5MM 1 C110E
06D348249400 Capacitor 824/63V ±5% 1 C108E
06D211064000 Capacitor 10UF/25V ±20% 4*7 105℃ 2.5MM 8
C21 C22 C101A C101B C101C C101D C101E
C205E
06D201066102 Capacitor 10UF/50V ф5*11MM ±20% 85℃ 2.5MM 1 C210E
06D214764000 Capacitor 47UF/25V ±20% 5*8 105℃ 2.5MM 4 C201A C201B C201C C201D
06S111046002 Capacitor SMD 104/50V ±10% X7R 0603 7 C5 C12 C16 C17 C19 C21L C22L
06S252263055 Capacitor SMD 22uF/16V 5*5.4 ±20% 105℃ 1 C25
06S254764065 Capacitor SMD 47uF/25V 6.3*5.4 ±20% 105℃ 2 C23 C24
06S324706000 Capacitor SMD 47PF/50V 0805 NPO ±5% 9
C102B C103B C102E C102A C103A C103D
C103C C102D C102C
12
KAPPA FIVE
