Part Number Qty
Reference Designator
Description
Control/Preamp/PWM PCB
06S121017000 Capacitor SMD 100PF/100V 0805 X7R ±10% 6 C26L C52 C202A C202B C202C C202D
06S121047000 Capacitor SMD 104/100V 0805 X7R ±10% 3 C20 C22S C43
06S138244001 Capacitor SMD 824PF/25V ±10% X7R 1206 TDK 2 C20L C31
06S132256000 Capacitor SMD 2.2uF/50V 1206 X7R ±10% 1 C44
06S134754000 Capacitor SMD 4.7UF/25V X7R ±10% 1206 3 C32 C33 C34
06S131063000 Capacitor SMD 10UF/16V ±10% X5R 1206 4 C49 C48 C6 C7
06S251074067 Capacitor SMD 100uF/25V 6.3*7.7 ±20% 105℃ 2 C30 C27
06S322206000 Capacitor SMD 22pF/50V 0805 NPO ±5% 2 C202E C106E
06S254746045 Capacitor SMD 0.47uF/50V 4*5.4 ±20% 105℃ 1 C27L
Semiconductors
03T1-F102-01 FET MPF102 TO-92 1 Q201E
01ST-L074-08 Quad Op-amp SMD TL074 SOP-14 3 U101A U101C U201E
04PT-4148-12 Diode SMD RLS4148 LL-34 11
D6 D7 D201E D204E D205E D206E D1 D8 D11
D12 D13
04WY-52C5-11 Zener Diode SMD 5V1 1/2W BZT52C5V1 SOD-123 1 Z1
04ZL-2512-00 Diode SMD MUR120 1A 2512 1 D7L
04WY-39AV101 Zener Diode SMD 3.9V DO-213AA 0.5W 1 ZD1
03P1-5401-04 Transistor SMD MMBT5401LT1 PNP SOT-23 6 Q2 Q5 Q6 Q7 Q8 Q13
03N1-5551-04 Transistor SMD MMBT5551LT1 NPN SOT-23 4 Q9 Q10 Q11 Q12
03P1-1015-04 Transistor SMD 2SA1015 SOT-23 PNP 1 Q1
03N1-1815-04 Transistor SMD 2SC1815 SOT-23 NPN 1 Q3
0100-74AH-00 Inverter 74AHC1G04 SOT-235 1 U3
0100-2010-00 IC IR2010S SOL-16 High and Low Side Driver 1 U1E
01TC-WH04-00 Triple Inverter TC7WH04F 1 U8
01TI-L494-09 PWM SMD TL494C SO-16 1 U1
01JR-4560-08 Dual Op-amp SMD 4560 SOP-8 JRC 7 U2 U100C U100D U100E U100A U100B U101E
Miscellaneous
1501-0809-09 PIN DIP 8P 180,6.0*2.54*3.0MM 2 J1B J2B
1501-0409-03 PIN DIP 4P 180,6.0*2.54*3.0MM 2 J3B J4B
1333-0211-00 Switch DIP SS-23D，16*6.5*21 MM,7MM 2P3T HPF/FULL/LPF 2 SW100A SW100C
1501-0309-05 Bend Pin DIP PITCH 2.54mm 3PIN 90 1 J2E
1501-0409-02 Bend Pin DIP PITCH 2.54mm 4PIN 90 2 J2F J5B
1502-0709-01 PIN DIP PITCH 2.54MM 1*7PIN 90 2 J3BA J3BB
24T1-125X089 Jumper DIP Φ0.8*12.5MM 1
Amplifier PCB
Resistors
0701-21R0-02 Resistor SMD 1Ω 1/8W ±5% 0805 4 R52 R69 R31 R32
0701-2100-02 Resistor SMD 10Ω 1/8W ±5% 0805 12
R16 R27A R28A R29A R30A R48 R49 R63 R67
R68 R15 R46
0701-2103-02 Resistor SMD 10KΩ 1/8W ±5% 0805 9 R21 R22 R25 R60 R26 R36 R38 R41 R59
0701-3103-02 Resistor SMD 10KΩ 1/4W ±5% 1206 4 R3 R4 R17 R57
0701-24R7-02 Resistor SMD 4.7Ω 1/8W ±5% 0805 8 R118A R13 R14 R42 R62 R117A R117B R118B
0701-2471-02 Resistor SMD 470Ω 1/8W ±5% 0805 4 R121B R121C R121D R121A
0701-2102-02 Resistor SMD 1KΩ 1/8W ±5% 0805 9
R112A R112B R112C R112D R128A R128B
R128C R128D RP1
0701-3102-02 Resistor SMD 1KΩ 1/4W ±5% 1206 4 R113A R113B R113C R113D
0701-2202-02 Resistor SMD R0805 2KΩ 1/8W ±5% 1 R33
0701-2222-02 Resistor SMD 2.2KΩ 1/8W ±5% 0805 1 RA149P
0701-2272-02 Resistor SMD 2.7KΩ 1/8W ±5% 0805 4 R7 R8 R34 R56
0701-2332-02 Resistor SMD 3.3KΩ 1/8W ±5% 0805 4 R11 R12 R53 R70
0701-2822-02 Resistor SMD 8.2KΩ 1/8W ±5% 0805 12 R1 R2 R5 R6 R9 R10 R18 R24 R23 R54 R55 R58
0701-2433-02 Resistor SMD 43K 1/8W ±5% 0805 4 R40 R44 R45 R61
0701-2473-02 Resistor SMD 47KΩ 1/8W ±5% 0805 8 R19 R20 R47 R64 R120A R120B R120C R120D
0701-2104-02 Resistor SMD 100KΩ 1/8W ±5% 0805 3 R35 R37 R39
0701-2222-04 Resistor SMD 2.2K 1/4W ±5% 1206 4 R123A R123B R123C R123D
0708-4100-02 Resistor 1W 10Ω ±5% 线绕 4 R122A R122B R122C R122D
KAPPA FIVE
