Part Number Qty
Reference Designator
Description
Amplifier PCB
Capacitors
06S321026000 Capacitor SMD 1000pF/50V 0805 NPO ±5% 8
C110A C110B C111A C111B C110C C110D
C111C C111D
06S121047001 Capacitor SMD 104/100V ±10% X7R 0805 TDK 16
C17 C18 C20 C27 C30 C37 C39 C6 C31 C41 C19
C1A C2A C3A C4A C5
06S13104C001 Capacitor SMD 104/250V ±10% X7R 1206 TDK 8 C13 C14 C15 C16 C28 C29 C38 C40
06S121017000 Capacitor SMD 100PF/100V 0805 X7R ±10% 4 C11 C25 C12 C35
06S432263000 Capacitor SMD 22uF/16V 1206 Y5V ＋80%/-20% 4 C7 C8 C24 C34
06S132256000 Capacitor SMD 2.2uF/50V 1206 X7R ±10% 13
K5 C1 C2 C9 C10 C22 C32 C33 C42 C108A
C108B C108C C108D
06S251064045 Capacitor SMD 10uF/25V 4*5.4 ±20% 105℃ 4 C3 C4 C26 C36
06S124736000 Capacitor SMD 0.047uF/50V 0805 X7R ±10% 2 C23 C21
06D344747000 Capacitor 474/100V ±5% 5MM 1 C1B
06D1C104C700 Capacitor 104/250V ±10%，CBB, Brown, 10MM 4 C114A C114B C114C C114D
06D1C105G701 Capacitor
105/160V ±10%，CBB, 11.5*8.5*15.5MM, 10.5MM,
Brown
4 C113A C113B C113C C113D
06D33221L000 Capacitor 221P/500V ±5% 4 C100A C100B C100C C100D
Semiconductors
03P1-5401-04 Transistor SMD MMBT5401LT1 PNP SOT-23 1 Q1
03N1-5551-04 Transistor SMD MMBT5551LT1 NPN SOT-23 1 Q7
04PT-4148-12 Diode SMD RLS4148 LL-34 9 D2 D5 D6 D8 D9 D10 D13 D14 D1
04ZL-2512-00 Diode SMD MUR120 1A 2512 4 D3 D4 D11 D12
03D1-6645-00 MOSFET IRF6645 8 Q3A Q4A Q5A Q6A Q2 Q8 Q13 Q14
0100-2095-00 IC IRS20955S Digital Audio Driver 4 U1 U3 U2 U4
01JR-4560-08 Dual Op-amp SMD 4560 SOP-8 JRC 2 U102A U102B
Miscellaneous
1001-1009-10 Inductor 10UH,ф15MM12MM :998AMF-101 4 L100A L100B L100C L100D
1004-0005-10 Inductor W5 RH 3.5*8*0.8-2 1 L1
1501-1209-07 Pin DIP 12P 180 6.0*14*4.0MM 2 CON2 CON4
1505-0209-00 Pin DIP 2*6P 180,6.0*14*4.0MM 1 CON1
LED Board
2009-0001-00 LED SMD 3.2*2.4*2.4 2 LED1 LED3
200A-0001-00 LED SMD 3.2*2.4*2.4 1 LED2
06S121046000 Capacitor SMD 0.1uF/50V 0805 X7R ±10% 2 C1 C2
2102-0057-05 FCC DIP 5Pin 2.0 UL1571 28AWG L=95MM 3MM 1 PR001
14
KAPPA FIVE
