KAPPA ONE Electrical Parts List
Part Number Qty Reference Designator
Main PCB
Resistors
0702-0106-03 Resistor 0.1Ω ±1% Ф1.5 10.5MM H16.5MM 4 7R R127 R126 R124
0701-A123-02 Resistor SMD 1W 12KΩ ±5% 2512 6 1R 2R 4R 3R R177 R176
0702-3103-02 Resistor 1/2W 10KΩ ±5%12.5MM 1 R69
0701-54R7-02 Resistor SMD 4.7Ω 1/2W ±5% 2512 1 R119
0705-5470-04 Resistor 5W 47Ω ±5% 13.5*9*23MM 1 R142
0701-2100-03 Resistor SMD 10Ω 1/8W ±1% 0805 6 R112 R111 R110 R109 R108 R107
0712-64R7-02 Resistor 2W 4.7Ω ±5% 10MM 1 R139
0701-A220-02 Resistor SMD 22Ω 1W ±5% 2512 3 R168 R167 R169
0704-6221-02 Resistor 2W 220Ω ±5% 1 R136
0701-3220-02 Resistor SMD 22Ω 1/4W ±5% 1206 2 6R 5R
0702-3331-02 Resistor 1/2W 330Ω ±5%12.5MM 2 R67 R66
0701-2101-03 Resistor SMD 100Ω 1/8W ±1% 0805 19
R188 R187 R166 R165 R164 R162 R161 R160
R47 R190 R189 R144 R128 R90 R89 R86 R74
R125 R101
0703-3222-03 Resistor 1/2W 2.2KΩ ±1% 1 R131
0701-3101-02 Resistor SMD 100Ω 1/4W ±5% 1206 2 R179 R178
0706-A222-02 Resistor 2.2KΩ 10W 22.5*13*13MM ±5% 1 R130
0701-2221-03 Resistor SMD 220Ω 1/8W ±1% 0805 2 R3 R60
0701-2821-02 Resistor SMD 820Ω 1/8W ±5% 0805 1 R50
0701-2221-03 Resistor SMD 220Ω 1/8W ±1% 0805 1 R2
0701-2102-03 Resistor SMD 1KΩ 1/8W ±1% 0805 7 R41 R42 R158 R157 R18 R54 R53
0701-2182-02 Resistor SMD 1.8KΩ 1/8W ±5% 0805 1 R19
0701-2222-02 Resistor SMD 2.2KΩ 1/8W ±5% 0805 4 R37 R135 R185 R140
0701-2302-03 Resistor SMD 3KΩ 1/8W ±1% 0805 1 R29
0701-2472-03 Resistor SMD 4.7KΩ 1/8W ±1% 0805 1 RX
0701-2512-02 Resistor SMD 5.1KΩ 1/8W ±5% 0805 3 R38 R81 R82
0701-2432-03 Resistor SMD 4.3KΩ 1/8W ±1% 0805 1 R27
0701-2103-03 Resistor SMD 10K 1/8W ±1% 0805 9 R61 R87 R22 R21 R28 R17 R33 R34 R197
0701-2333-03 Resistor SMD 33KΩ 1/8W ±1% 0805 3 R31 R30 R184
0701-2223-03 Resistor SMD 22KΩ 1/8W ±1% 0805 4 R36 R20 R4 R1
07012487YK03 Resistor SMD 48.7KΩ 1/8W ±1% 0805 1 R80
0701-2473-03 Resistor SMD 47KΩ 1/8W ±1% 0805 22
R5 R25 R24 R194 R181 R77 R26 R14 R11 R8 R7
R10 R180 R59 R196 R195 R75 R68 R23 R13 R9
R6
0701-2183-03 Resistor SMD 18KΩ 1/8W ±1% 0805 1 R12
0701-2104-03 Resistor SMD 100KΩ 1/8W ±1% 0805 4 R83 R63 R62 R16
0701-2622-03 Resistor SMD 6.2K
Ω 1/8W ±1% 0805 1 R35
0701-2332-03 Resistor SMD 3.3KΩ 1/8W ±1% 0805 1 R134
0701-2511-02 Resistor SMD R0805 510Ω 1/8W ±5% 1 R39
0701-2133-02 Resistor SMD 1/8W 13KΩ ±5% 0805 1 R15
0701-2164-03 Resistor SMD 160K 1/8W ±1% 0805 1 R40
0704-4123-02 Resistor 1W 12K ±5% 15MM 1 R120
0701-2682-03 Resistor SMD 6.8KΩ 1/8W ±1% 0805 1 R32
1204-2040-01 VR, HP FREQ B200K/B2K L=15 ±10% B200K,B2K 1 VR3
1204-2030-01 VR, LEVEL B20K L=15 ±10% ＜2.5dB 1 VR1
1204-5031-30 VR, LP FREQ B50K ±10% :R0971G KQ 1 VR2
1204-5011-01 VR, BOOST B500Ω KQ L=15 ±15% 1 VR4
Capacitors
06D1C3357700 Capacitor
3.3UF/100V ±10% MAX：24*18.5*10.5MM
20MM CBB21
1 C105
06D2C335C701 Capacitor 3.3UF/250V ±20% 105℃ 27mm CBB21 1 C96
06D2C1067001 Capacitor 10UF/100V±20% 20MM 10.5MM 5 C141 C106 C101 11C 12C
06D212266010 Capacitor 22uF/50V ±20% 5*11 105℃5.0MM 11 C9 C6 C5 C11 C41 C31 C10 C8 C7 C4 C3
06D102266000 Capacitor 22UF/50V ±10% Φ6.3*11 85℃ NP 1 C119
06D214765000 Capacitor 47UF/35V ±20% 5*11 105℃5MM 3 C50 C49 C35
06D211073116 Capacitor 100UF/16V ±20% 5*11 105℃5MM 3 C131 C130 C129
06D214775101 Capacitor 470UF/35V ±20% Ф8*20MM 105℃ 3 C134 C133 C127
