Part Number Qty Reference Designator
Description
Main PCB
06D212285001 Capacitor
2200UF/35V 16*26MM ±20% 105℃ 7.5MM
SUSCON
4 C112 C111 C110 C109
06D213387002 Capacitor 3300UF/100V 35MM*25MM ±20% 105℃ 4 C148 C147 C146 C145
06D231047000 Capacitor 0.1uF/100V ±20%5MM 1 C122
06D3C104C701 Capacitor 104/250V ±5% 5mm 3 C139 C86 C65
06D942247401 Capacitor 224/100V ±2% 7.2*8.5*3.5MM 5MM 2 C103 C102
06D184717400 Capacitor 471/100V X7R ±10% 1 C124
06D1C4747701 Capacitor 474/100V ±10% 7.5mm 4 C99 C98 C152 C135
06D342749400 Capacitor 274/63V ±5% 5MM 1 C2
06D344737400 Capacitor 473/100V ±5% 1 C47
06S15101F000 Capacitor SMD 101/1KV ±10% X7R 1206 1 CX100
06D941247401 Capacitor 124/100V ±2% 7.2*6.5*3.0MM 5MM 1 C46
06S15222F000 Capacitor SMD 222/1KV ±10% X7R 1206 1 C97
06D322227200 Capacitor 222/100V ±5% 5MM 4 15C CX1 C24 C23
06S321006000 Capacitor SMD 10pF/50V 0805 NPO ±5% 3 C14 C12 C13
06S322206000 Capacitor SMD 22pF/50V 0805 NPO ±5% 2 C33 C32
06S321016000 Capacitor SMD 100pF/50V 0805 NPO ±5% 13
C40 C22 C36 C15 C44 C38 C37 C17 C16 14C
13C 3C 4C
06S121046000 Capacitor SMD 0.1uF/50V 0805 X7R ±10% 28
C121 C120 C138 C137 C118 C76 C51 C48 C21
C20 C19 C18 C108 C90 C115 C128 C116 C29
C28 C27 C26 JP428 JP426 7C 5C 8C 2C 1C
06S321026000 Capacitor SMD 1000pF/50V 0805 NPO ±5% 4 C42 9C 6C C25
06S121244000 Capacitor SMD 0.12UF/25V 0805 X7R ±10% 1 C123
06S124716000 Capacitor SMD 470pF/50V 0805 X7R ±10% 4 C30 C150 C149 CX2
06S131037000 Capacitor SMD 103/100V X7R ±10% 1206 2 C126 C125
06D201066200 Capacitor 10UF/50V ±20% 5*11 85℃ 5mm 2 C34 C39
06D2410644CB Capacitor SMD 10uF/25V CASE-D ±20% 2 C76 C136
06D212256301 Capacitor 2.2UF/50V ±20% 5*11 105℃ 5mm 1 C43
06D348249400 Capacitor 824/63V ±5% 1 C1
Semiconductors
04ZL-6A10-00 Diode 6A10 1000V 1 D17
04ZL-4007-03 Diode 1N4007 DO-41 1 D16
04GS-R104-00 Diode FR104 1A 400V 52MM 4 D29 D28 D27 D26
03D1-TP50-24 MOSFET TP50N20P TO-220 6 Q14 Q13 Q12 Q11 Q10 Q9
01FA-7812-04 Regulator KA7812E TO-220 FAIRCHILD +12v 2 U13 U15
01FA-7912-04 Regulator KA7912 TO-220 FAIRCHILD -12v 1 U14
04PT-4148-01 Diode SMD 1N4148 DO-213AA 13
D51 D1 DX1 D2 D14 D13 D12 D11 D10 D9 D6 D3
D4
04ZL-2512-00 Diode SMD MUR120 1A 2512 2 D35 D34
2202-1602-05 Bridge UF1602CT AKA 16/200V TO-220 2 D31 D30
03N1-5551-04 Transistor SMD MMBT5551LT1 NPN SOT-23 1 Q3
2202-20RG-05 Bridge
MUR1620RG KAK 16A/200V TO-220 ON
SEMI
2 D33 D32
03N1-2222-04 Transistor SMD BT2222 SOT-23 NPN 1 Q29
04WY-51AV101 Diode SMD 5.1V DO-213AA 0.5W 2 DZ3 DZ2
04ZL-4007-02 Diode SMD FM4007 DO-214AC 3 D25 D24 D23
0100-M833-08 Dual Op-amp SMD LM833 SOP-8 7 U6 U3 U7 U1 U5 U4 U2
04GS-RS1G-02 Diode SMD RS1G 400V 1A DO-214AC 5 D22 D21 D20 D7 D5
03T1-3205-02 MOSFET IRF3205 110A 50V TO-220 6 Q28 Q27 Q26 Q24 Q23 Q22
03T1-K30A-01 FET 2SK30A TO-92 1 Q1
01TI-L072-09 Dual Op-amp SMD TL072 SO-8 1 1U1
04WY-12BV101 Diode SMD 12V DO-213AA 0.5W 1 DZ1
0100-78M1-07 Regulator SMD 78M12 TO-252 +12v 1 U8
Miscellaneous
1404-0020-04 RCA QUAD AV4-8.4-38 JACKS 1 J1
1601-403G-01 Fuse 40A/32V UL Littelfuse 6 F1
1401-0001-03 Fuse holder 3PIN :BXS3-09 1 for F1
1380-0214-00 Temperature switch 90℃±5℃ TO-220 PCS 1 SW1
1003-1002-08 Inductor SMD 10UH CPL-0805 20MA ±20% 2 L1 DX2
KAPPA ONE
