Part Number Qty Reference Designator
Description
Main PCB
3000-MONE-01 HF transformer
4:24:6:7 F1=F2=φ1.0*8*4TS
S1=S2=φ0.8*5*24TS S3=S4=φ0.8*1*6TS
S5=S6=φ0.8*1*7TS
1L8
2901-224C-00 Relay YL-224-C DC12V 30A 1 RL1
1004-3003-10 Inductor 90 30UH φ12φ5 2 L12 L11
1001-1820-10 Inductor
ф32 1.8MH L1=L2 ф1.0*12 4TS 38*22MM
42MM
1L6
1001-4000-10 Inductor 40UH 40A ETD-49 φ0.1*80*14TS 1 L4
1501-0300-04 Terminal JS23A-25A 3PIN POWER 1 CN3
1501-0400-02 Terminal JS24A-23A 4PIN 2个2个 SPEAKER 1 CN2
1501-0404-00 Socket Pitch 2.0MM 4PIN 1 CN1
24D1-0070190 Grounding UL1015#18AWG L=70MM 2 JK1 JK2
1001-3501-10 Inductor 35UH Φ33Φ0.3*18*2 29MM 1 L5
2102-0052-04 FFC
4P 1430.26L=80MM一5MM一2.0105℃
1 connect to the LED board
1501-0300-05 Terminal 3P JSZ3-83 180 1 Accessory
1400-0001-16 RJ45 socket 16PIN RJ45 10P16C 1 RJ1
PWM PCB
Resistors
0701-2221-03 Resistor SMD 220Ω 1/8W ±1% 0805 1 2R65
0701-2102-03 Resistor SMD 1KΩ 1/8W ±1% 0805 5 2R156 2R155 2R5 R8 R9
0701-2202-02 Resistor SMD R0805 2KΩ 1/8W ±5% 2 2R33 2R138
0701-2222-02 Resistor SMD 2.2KΩ 1/8W ±5% 0805 2 2R200 2R132
0701-2472-03 Resistor SMD 4.7KΩ 1/8W ±1% 0805 2 2R147 2R46
0701-2682-03 Resistor SMD 6.8KΩ 1/8W ±1% 0805 1 2R102
0701-2103-03 Resistor SMD 10K 1/8W ±1% 0805 5 2R99 2R137 2R78 2R34 2R146
0701-2113-03 Resistor SMD 11KΩ 1/8W ±1% 0805 1 2R171
0701-2123-03 Resistor SMD 12KΩ 1/8W ±1% 0805 2 2R35 2R149
0701-2183-03 Resistor SMD 18KΩ 1/8W ±1% 0805 1 2R1
0701-2203-03 Resistor SMD 20KΩ 1/8W ±1% 0805 1 2R104
0701-2303-02 Resistor SMD 30KΩ 1/8W ±5% 0805 1 2R175
0701-2333-03 Resistor SMD 33KΩ 1/8W ±1% 0805 1 2R98
0701-2473-03 Resistor SMD 47KΩ 1/8W ±1% 0805 7 2R3 2R44 2R97 2R4 2R20 2R145 2R19
0701-2753-03 Resistor SMD 75KΩ 1/8W ±1% 0805 1 2R103
0701-2104-03 Resistor SMD 100KΩ 1/8W ±1% 0805 3 2R2 2R148 2R154
Capacitors
06S321026000 Capacitor SMD 1000pF/50V 0805 NPO ±5% 1 2C143
06S121047000 Capacitor SMD 104/100V 0805 X7R ±10% 12
2C1 2C132 2C84 2C81 2C22 2C79 2C117 2C82
2C34 2C80 2C89 2C151
06D252274000 Capacitor 220UF/25V 8*9 ±20% 105℃ 2 2C88 2C87
06D211074101 Capacitor 100UF/25V 6.3*7mm 5mm ±20% 105℃ 1 2C2
Semiconductors
04PT-4148-01 Diode SMD 1N4148 DO-213AA 10
2D1 2D42 2D46 2D47 2D45 2D43 2D2 2D5 2D18
2D19
03N1-5551-04 Transistor SMD MMBT5551LT1 NPN SOT-23 10
2Q38 2Q8 2Q7 2Q5 2Q6 2Q37 2Q2 2Q33 2Q3
2Q4
03P1-5401-04 Transistor SMD MMBT5401LT1 PNP SOT-23 1 2Q32
01TI-L494-09 PWM SMD TL494C SO-16 1 2U18
04WY-39AV101 Diode SMD 3.9V DO-213AA 0.5W 1 2D15
03P1-1023-01 Transistor A1023 TO-92 PNP 2 2Q20 2Q19
03P1-B649-07 Transistor 2SB649A 1.5A 180V 20W PNP TO-126 1 2Q17
Miscellaneous
1506-0805-00 Pin 8PIN 902.5MM 2.75MM 2 2CN1 2CN2
KAPPA ONE
To Next Page
