Part Number Qty Reference Designator
Description
PROCESSOR PCB
Resistors
0701-2104-03 Resistor SMD 100KΩ 1/8W ±1% 0805 1 R64
0701-2103-03 Resistor SMD 10K 1/8W ±1% 0805 5 R33 R30 R31 R3 R2
0701-2100-03 Resistor SMD 10Ω 1/8W ±1% 0805 4 R117 R193 R198 R118
0701-2102-03 Resistor SMD 1KΩ 1/8W ±1% 0805 2 R55 R58
0701-2222-02 Resistor SMD 2.2KΩ 1/8W ±5% 0805 2 R105 R106
0701-2472-03 Resistor SMD 4.7KΩ 1/8W ±1% 0805 4 R44 R41 R42 R43
0701-2622-03 Resistor SMD 6.2KΩ 1/8W ±1% 0805 1 R40
0701-2681-02 Resistor SMD 680Ω 1/8W ±5% 0805 3 R45 R116 R199
0701-2152-02 Resistor SMD 1.5KΩ 1/8W ±5% 0805 1 R56
0701-2101-03 Resistor SMD 100Ω 1/8W ±1% 0805 3 R191 R192 R49
0701-2303-03 Resistor SMD 30K 1/8W ±1% 0805 1 R29
0701-2221-03 Resistor SMD 220Ω 1/8W ±1% 0805 1 R113
0701-2331-02 Resistor SMD 330Ω 1/8W ±5% 0805 1 R48
0701-2473-03 Resistor SMD 47KΩ 1/8W ±1% 0805 1 R57
Capacitors
06S321026000 Capacitor SMD 1000pF/50V 0805 NPO ±5% 1 C100
06S321016000 Capacitor SMD 100pF/50V 0805 NPO ±5% 2 C62 C61
06S121046000 Capacitor SMD 0.1uF/50V 0805 X7R ±10% 8 C57 C59 C75 C77 C60 C63 C91 C92
06S132253000 Capacitor SMD 2.2uF/16V 1206 X7R ±10% 2 C104 E1
06S123326000 Capacitor SMD 332/50V ±10% X7R 0805 1 C64
06S2410724CC Capacitor SMD 100UF/10V CASE-C ±20% 1 C58
06S124727000 Capacitor SMD 472/100V 0805 X7R ±10% 2 C55 C56
06S2447634CC Capacitor SMD 47uF/16V CASE-C ±20% 1 C43
06S2447644CD Capacitor SMD 47uF/25V CASE-D ±20% 2 C93 C94
Semiconductors
01JR-4560-08 Dual Op-amp SMD 4560 SOP-8 JRC 1 U8
2601-4N35-00 photocoupler 4N35 6 1 U17
01LM-M555-08 Timer SMD LM555 SOP-8 1 U7
0100-2010-00 Hi/Lo Side Driver IR2010S SOL-16 1 U10
03P1-5401-04 Transistor SMD MMBT5401LT1 PNP SOT-23 1 Q30
01TC-WH04-00 Triple Inverter TC7WH04F 1 U9
0100-74AH-00 Inverter 74AHC1G04 SOT-235 1 U16
04ZL-2512-00 Diode SMD MUR120 1A 2512 1 D8
01LM-M311-08 Comparator SMD LM311 SOP-8 1 U11
04PT-4148-01 Diode SMD 1N4148 DO-213AA 5 D3 D7 D4 D2 D49
04WY-51AV101 Diode SMD 5.1V DO-213AA 0.5W 1 DZ1
Miscellaneous
1505-1009-04 Pin PITCH 2.54mm 10PIN 912.75MM 2 CN6 CN5
LED PCB
2009-0001-00 LED SMD White with blue light, 3.2*2.4*2.4 2 LED1 LED3
200A-0001-00 LED SMD White with red light, 3.2*2.4*2.4 1 LED2
06S121046000 Capacitor SMD 0.1uF/50V 0805 X7R ±10% 2 C1 C2
MECHANICAL
SR-APPA-0124 Heatsink Alum.6063-T5,290*177.7*37.5MM Black
SG-0011-0501 Top plate Alum. alloy ADC-12,290*154.8*9.7MM black painting
ZS-A00010133 Side bar Alum. 6063-T5,19*290.2MM Plating
CP-A00020002 Top plastic
Clear PC,262.2*70MM black painitng with
"INFINITY"LOGO holofoil
SG-0001-0133 Side panel
Alum. alloy ADC-12,178.9*19.6*39.9MM
plating
MK-0127-0507 Front plate 171.8*37.1*1.2MM black painting + silkscreen
HG-0037-0507 Rear plate 171.8*37.1*1.2MM black painting + silkscreen
KAPPA ONE
