4 TOLL FREE: 1-888-668-9600
2
1
a
c
b
d
e
g
*h *i
f
3
5
4
Along with your upright unit, you will
find the following components:
a Detachable Handle (Ergonomic Grip)
b Telescopic Wand
c Cleaning Attachments
d Upper Hose Holder
e Extra Filters
f Super Stretch Hose
g Spare Motor Belt
*
Note: depending on the model you
select, your Infinity comes with a Pet Hair
Power Brush (
h
) and Low Reach Bare Floor
Brush (
i
) that are kept in a separate
accessory bag.
Your Infinity Upright is a snap to
assemble:
1 Lock into upright position.
2 Attach the Upper Hose Holder: use a
Phillips Head screwdriver to remove
the screw attached to the vacuum
body.
3 Place the Upper Hose Holder into the
slot; screw the holder onto the
vacuum body.
4 Slide the Telescopic Wand into the
upright unit to click in place.
5 Slide the Detachable Handle onto
the Telescopic Wand.
Getting Started
