[ Edit: 2016/ 8/ 1 Model: 2017MY INFINITI Q70(Y51) OM17E00Y51U0 ]
4-34 Monitor, climate, audio, phone and voice recognition systems
Available views
GUID-1E4D76D9-CF3D-4423-8BA0-21F1DA9564AE
WARNING
. The distance guide lines and the vehicle
width lines should be used as a refer-
ence only when the vehicle is on a
paved, level surface. The apparent dis-
tance viewed on the monitor may be
different than the actual distance be-
tween the vehicle and displayed objects.
. Use the displayed lines and the bird’s-
eye view as a reference. The lines and the
bird’s-eye view are greatly affected by
the number of occupants, fuel level,
vehicle position, road condition and road
grade.
. If the tires are replaced with different
sized tires, the predictive course lines
and the bird’s-eye view may be dis-
played incorrectly.
. When driving the vehicle up a hill,
objects viewed in the monitor are further
than they appear. When driving the
vehicle down a hill, objects viewed in
the monitor are closer than they appear.
. Objects in the monitor will appear
visually opposite compared to when
viewed in the rear view and outside
mirrors.
. Use the mirrors or actually look to
properly judge distances to other ob-
jects.
. The distance between objects viewed in
the rear view differs from actual distance
because a wide-angle lens is used.
. On a snow-covered or slippery road,
there may be a difference between the
predictive course line and the actual
course line.
. The vehicle width and predictive course
lines are wider than the actual width and
course.
. The displayed lines on the rear view will
appear slightly off to the right because
the rear view camera is not installed in
the rear center of the vehicle.
SAA1840
Front view
SAA1896
Rear view
Condition:
