[ Edit: 2016/ 8/ 1 Model: 2017MY INFINITI Q70(Y51) OM17E00Y51U0 ]
WARNING
Failure to follow the warnings and instruc-
tions for proper use of the Moving Object
Detection system could result in serious
injury or death.
. The MOD system is not a substitute for
proper vehicle operation and is not
designed to prevent contact with the
objects surrounding the vehicle. When
maneuvering, always use the outside
mirror and rearview mirror and turn and
check the surrounding to ensure it is
safe to maneuver.
. The system is deactivated at speeds
above 5 MPH (8 km/h). It is reactivated
at lower speeds.
. The MOD system is not designed to
detect the surrounding stationary ob-
jects.
The Moving Object Detection (MOD) system
can inform the driver of the moving objects
surrounding the vehicle when driving out
of garages, maneuvering into parking lots
and in other such instances.
The MOD system detects moving objects by
using image processing technology on the
image shown on the display.
MOD SYSTEM OPERATION
GUID-2C61614B-E471-4566-A778-2CE9605D3242
The MOD system will turn on automatically
under the following conditions:
. When the shift lever is in the “R”
(Reverse) position.
. When the CAMERA button is pushed to
activate the camera view on the dis-
play.
. When vehicle speed decreases below
approximately 5 MPH (8 km/h) .
. When the ignition switch is placed in
the “OFF” position and then back to the
“ON” position.
When the MOD system detects moving
objects near the vehicle, the yellow frame
will be displayed on the view where the
objects are detected and a chime will
sound once. While the MOD system con-
tinues to detect moving objects, the yellow
frame continues to be displayed.
JVH1146X
Bird’s-eye view
JVH1147X
Front view / rear view
Monitor, climate, audio, phone and voice recognition systems 4-51
