Infinity QPS-1 – Owner’s Manual
PLACEMENT AND MOUNTING
The Infinity QPS-1 surround speakers are equipped with integral display stands for easy
placement on a shelf or table.
QPS-1
(Table-Top Placement)
Bottom View
T ABLE -T OP P LACEMENT ...
W
ALL -M OUNT O PTIONS ...
I
MPORTANT !
Figure 3. Use the built-in keyhole to mount
QPS-1 surround speakers on walls.
NOTE: Be sure to fasten each #8 x 1
1
/2 "
Phillips-head wood screw into a wall
stud before hanging the speaker.
For wall-mounting, you can use the speaker’s keyhole (see Figure 3).
If you are unsure of how to safely and securely wall-mount a speaker, please ask a home
theater or hardware specialist for additional help.
QPS-1
(Wall-Mount Via Keyhole)
❶ Fasten #8 x 1
1
⁄2"
Phillips-head
wood screw
into wall stud;
leave
1
⁄16" space
from head to wall.
❷ Align keyhole with
screw head and
slide speaker down.
