4. Remove wiper blade j 1inthe direction of
arrow
j 5.
Fitting the wiper blades
1. Position new wiper blade j 1with recess j 6
on lug
j 5.
2. Move wiper blade
j 1inthe direction of ar-
row
j 3onto the wiper arm until retaining
clips
j 2engageinbracket j 4.
3. Makesure that wiper blade
j 1isseated cor-
rectly.
4. Move the wiper arm backonto the
windscreen.
BACK DOOR WINDOW WIPER
REPLACEMENT
Removing the wiper blade
1. Move wiper arm j 4awayfrom the rear win-
dow.
2. Pressboth releaseclips
j 2.
NDI1587
NDI1588
Maintenanceand do-it-yourself 8-15
