Rearlight unit
j
1
Tail light
j
2
Turn signal light
j
3
Brakelight
j
4
Tail light
j
5
Reversing light
j
6
Rearfog light (drivers side only)
REPLACING BULBS
LED lights (where fitted)
TheLED headlightisaprojector stylewhichuses
aLED module without serviceable parts. These
and otherLED lights must be replaced by an
INFINITI centre or qualified workshop.
CAUTION
•
To prevent an electric shock, never attempt to
modify or disassemble the LED headlights assem-
bly.
•
If replacement of LED lights is required, contact an
INFINITI centre or qualified workshop.
Replacing the halogen headlight bulb
CAUTION
•
High pressure halogen gas is sealed inside the
halogen bulb. The bulb maybreak if the glass en-
velope is scratched or the bulb is dropped.
•
When handling the bulb, DO NOTTOUCH THE
GLASSENVELOPE.
•
Usethe same number type and wattageasorigi-
nallyinstalled.
•
Aiming is usually notnecessaryafter replacingthe
bulb.When aiming adjustment is necessary,con-
tact an INFINITI centre or qualified workshop.
•
Do notleave the bulb out of the headlightreflector
foralong periodoftime asdust, moistureor smoke
mayenter the headlight body and affect the per-
formanceofthe headlight.
Fitting/removing the access cover on the front
wheelarch:
Youmustremove the cover of the front wheel
archbefore youcan change the halogen head-
lightbulb.
To remove: switch off the lights, turn the steer-
ing so that the wheelbehind the light in ques-
tion is pointing inwards. Slide cover
j
1upand
removeit.
To fit: inset cover
j
1again and slide it down
untilitengages.
The headlight is asemi-sealed beam type which
usesareplaceableheadlight (halogen) bulb.A
bulb canbereplaced from inside the engine
compartment without removing the headlight
ass
embly.
Co
ntact an INFINITI
ce
ntre or qualified
workshop, if youneed assistancefor bulb re-
placement.
NDI1615 NDI1626
Maintenanceand do-it-yourself 8-25
