Infinity Reference Series 1300a User Manual

REFERENCE 1300a Electrical Parts List
Part Number Qty Reference Designator
MAIN BOARD
Resistors
0702-10R0-02 Resistor CARBON 1/8W 0Ω ±5% 9 R34 R35 R61 L1 L2 L3 L4 JP140 JP141
0702-34R7-02 Resistor 1/2W 4.7Ω ±5% 3 R242 R36 R37
0702-1220-02 Resistor 1/8W 22Ω ±5% 5 R112 R210 R211 R212 R213
0702-1680-02 Resistor 1/8W 68Ω ±5% 2 R202 R203
0702-1101-02 Resistor 1/8W 100Ω ±5% 7 R42 R132 R133 R134 R136 R137 R138
0702-1221-02 Resistor 1/8W 220Ω ±5% 5 R145 R129 R130 R131 R207
0702-1471-02 Resistor 1/8W 470Ω ±5% 1 R240
1201-1021-03 Variable Resistor 1k Ω 1 RW200
0702-1561-02 Resistor 1/8W 560Ω ±5% 2 R127 R128
0702-1751-02 Resistor 1/8W 750Ω ±5% 1 R38
0702-1102-02 Resistor 1/8W 1KΩ ±5% 10
R25
R30
R31
R32
R33
R113
R114
R200
R201
R105A
0702-1152-02 Resistor 1/8W 1.5KΩ ±5% 6 R238 R241 R249 R250 R252 R253
0702-1182-02 Resistor 1/8W 1.8KΩ ±5% 1 R41
0702-1202-02 Resistor 1/8W 2KΩ ±5% 3 R104 R219 R115
0702-1222-02 Resistor 1/8W 2.2KΩ ±5% 4 R124 R217 R218 R204
0702-1332-02 Resistor 1/8W 3.3KΩ ±5% 1 R120
0702-1472-02 Resistor 1/8W 4.7KΩ ±5% 5 R109 R110 R205 R26 R39
0703-1652-03 Resistor 1/8W 6.5KΩ ±1% 1 R106A
0702-1682-02 Resistor 1/8W 6.8KΩ ±5% 5 R159 R157 R214 R215 R216
0702-1752-02 Resistor 1/8W 7.5KΩ ±5% 2 R50 R51
0702-1103-02 Resistor 1/8W 10KΩ ±5% 14
R117 R21 R22 R27 R55 R62 R100 R101 R102 R103
R105 R121 R122 R125
0702-1113-02 Resistor 1/8W 11KΩ ±5% 1 R158
0702-1123-02 Resistor 1/8W 12KΩ ±5% 1 R154
0702-1133-02 Resistor 1/8W 13KΩ ±5% 1 R19
0702-1153-02 Resistor 1/8W 15KΩ ±5% 4 R152 R239 R256 R110A
0702-1203-02 Resistor 1/8W 20KΩ ±5% 3 R17 R18 R119
0702-1223-02 Resistor 1/8W 22KΩ ±5% 8 R106 R108 R147 R208 R1 R2 R7 R109A
0702-1243-02 Resistor 1/8W 24KΩ ±5% 2 R40 R209
0702-1303-02 Resistor 1/8W 30KΩ ±5% 1 R153
0702-1333-02 Resistor 1/8W 33KΩ ±5% 1 R118
0702-1473-02 Resistor 1/8W 47KΩ ±5% 23
R13
R16
R20
R23
R24
R28
R29
R60
R63
R126
R107 R3 R4 R5 R6 R8 R9 R10 R11 R12 R14 R15
R64
0702-1563-02 Resistor 1/8W 56KΩ ±5% 3 R150 R58 R235
0702-1623-02 Resistor 1/8W 62KΩ ±5% 2 R48 R49
0702-1823-02 Resistor 1/8W 82KΩ ±5% 1 R59
0702-1104-02 Resistor 1/8W 100KΩ ±5% 6 D111 R149 R53 R54 R155 R156
0702-1154-02 Resistor 1/8W 150KΩ ±5% 2 R56 R57
0702-1334-02 Resistor 1/8W 330KΩ ±5% 1 R151
0702-1474-02 Resistor 1/8W 470KΩ ±5% 1 R206
0702-1205-02 Resistor 1/8W 2MΩ ±5% 1 R44
0702-3101-02 Resistor 1/2W 100Ω ±5% 2 R222 R223
0702-24R7-02 Resistor 1/4W 4.7Ω ±5% 6 R225 R226 R227 R228 R229 R231
0702-3271-02 Resistor 1/2W 270Ω ±5% 2 R220 R221
0702-2103-02 Resistor 1/4W 10KΩ ±5% 2 R143 R144
0702-2203-02 Resistor 1/4W 20KΩ ±5% 1 R148
0705-515X-07 Cement Resistor 5W 0.15Ω ±5% 6 R233 R234 R236 R237 R259 R260
1204-5031-30 Variable Resistor B50K ±10% LEVEL 1 VR1
1204-1041-07 Variable Resistor B100K ±10% LP FREQ. 1 VR2
Description
10
1300a Reference Series
