Infinity Reference Series 1300a User Manual

Part Number Qty Reference Designator
Description
MAIN BOARD
1204-5041-05 Variable Resistor C500K ±10% BASS BOOST 1 VR3
0704-6202-02 Resistor 2W 2KΩ ±5% 2 R107A R108A
0702-3220-02 Resistor 1/2W 22Ω ±5% 3 R142 R141 R140
0702-1201-02 Resistor 1/8W 200Ω ±5% 1 R45
0702-1562-02 Resistor 1/8W 5.6KΩ ±5% 1 R46
0702-1822-02 Resistor 1/8W 8.2KΩ ±5% 1 R123
Capacitors
06D212246001 CAP,Electro 0.22UF/50V φ5*11mm ±20% 105℃ 2 C110 C112
06D212256301 CAP,Electro 2.2UF/50V ±20% 5*11 105℃ 1 C208
06D212266010 CAP,Electro 22uF/50V ±20% 5*11 105℃ 12 C3 C204 C4 C5 C7 C8 C9 C10 C12 C13 C14 C103
06D214766109 CAP,Electro 47uF/50V ±20% 5*11 105℃ 2 C35 C36
06D214764102 CAP,Electro 47uF/25V ±20% 5*11 105℃ 2 C139 C102
06D211073116 CAP,Electro 100UF/16V±20% 5*11 105℃ 3 C137 C138 C104
06D212273109 CAP,Electro 220uF/16V ±20% 5*11 105℃ 2 C209 C140
06D21477H100 CAP,Electro 470UF/80V ±20% φ16*25mm 2 C135 C136
06D214775117 CAP,Electro 470uF/35V ±20% 10*17 105℃ 2 C133 C134
06D214789100 CAP,Electro 4700UF/63V ±20% φ35*27mm 2 C144 C145
06D212274001 CAP,Electro 220UF/25V ±20% 8*12 105℃ 3 C1 C2 C207
06D212285101 CAP,Electro 2200UF/35V Φ16*26MM ±20% 105℃ 4 C122 C123 C125 C124
06D231017000 Ceramic Capacitor 100pF/100V ±20% 11 C23 C24 C15 C16 C18 C19 C20 C21 C22 C56 C17
06D231047000 Ceramic Capacitor 0.1uF/100V ±20% 28
C101 C1A C1B C25 C26 C27 C28 C29 C30 C31 C3
2
C33 C34 C100 C111 C114 C115 C117 C118 C119
C120 C121 C6 C53 C54 C55 C128 C129
06D232217000 Ceramic Capacitor 220pF/100V ±20% 1 C38
06D234717001 Ceramic Capacitor 470PF/100V ±20% 1 C37
06D232207000 Ceramic Capacitor 22pF/100V ±20% 2 C42 C44
06D235607000 Ceramic Capacitor 56PF/100V ±20% 2 C201 C202
06D236817000 Ceramic Capacitor 680pF/100V ±20% 2 C200 C203
06D234737001 Ceramic Capacitor 473/100V ±20% 1 C205
06D321027200 Ceramic Capacitor 102/100V ±5% 2 C141 C142
06D321037200 Ceramic Capacitor 103/100V ±5% 2 C126 C127
06D321047200 Ceramic Capacitor 104/100V ±5% 8 C48 C116 C130 C131 C132 C146 C147 C206
06D211074100 CAP,Electro 100uF/25V ±20% 6.3*11 105℃ 2 C148 C143
06D321839200 Ceramic Capacitor 183/63V ±5% 3 C50 C51 C52
06D343939400 Ceramic Capacitor 393/63V ±5% 1 C49
06D323349000 Ceramic Capacitor 334/63V ±5% 2 C46 C47
06D342249400 Ceramic Capacitor 224/63V ±5% 2 C210 C211
Semiconductors
04WY-82AV104 Zener Diode 8.2V DO-35 0.5W 1 DZ100
04ZL-6A10-00 Diode 6A10 1000V 1 D106
04WY-56AV104 Zener Diode 5.6V 0.5W 20MA 52MM DO-35 0.5W 1 DZ101
04PT-4148-04 Diode 1N4148 GSS 200MA 75V DO-35 12
D100 D101 D102 D103 D104 D105 D200 D201 D20
2
D204 D205 D208
04GS-R104-00 Diode FR104 1A 400V 52MM 4 D117 D118 D119 D120
04GS-R204-00 Diode FR204 2A 400V 52MM 4 D107 D108 D109 D110
04WY-39AV104 Zener Diode 3.9V DO-35 0.5W 1 DZ101A
03P1-1015-01 Transistor 2SA1015 150MA 60V 400MW PNP TO-92 5 Q107 Q108 Q109 Q111 Q112
03P1-A940-02 Transistor 2SA940 PNP TO-220 2 Q218 Q217
11
1300a Reference Series
