Infinity Reference Series 1300a User Manual

Part Number Qty Reference Designator
Description
MAIN BOARD
03N1-5551-01 Transistor 2N5551 NPN TO-92 4 Q1 Q210 Q211 Q212
03P1-5401-01 Transistor 2N5401 PNP TO-92 2 Q214 Q215
03P1-1695-13 Transistor 2SA1695 PNP TO-3P 3 Q219 Q220 Q222
03P1-B647-01 Transistor 2SB647 1A 120V 0.9W PNP TO-92 1 Q200
03P1-B649-07 Transistor 2SB649A 1.5A 180V 20W PNP TO-126 1 Q110
03N1-1815-01 Transistor 2SC1815GR 150MA 60V NPN TO-92 11
Q122 Q100 Q101 Q102 Q103 Q104 Q105 Q106
Q121 Q208 Q209
03N1-2073-02 Transistor 2SC2073 NPN TO-220 3 Q202 Q201 Q213
03N1-4468-13 Transistor 2SC4468 NPN TO-3P 3 Q204 Q205 Q206
03N1-667A-01 Transistor 2SD667AC 1A 120V 0.9W NPN TO-92 1 Q216
03N1-8050-01 Transistor S8050 NPN TO-92 1 Q207
01UT-L494-01 IC PWM DIP TL494 DIP16 1 U102
01JR-4560-01 IC DIP NJM4560D Dual Op-amp DIP-8 5 U2 U4 U5 U1 U3
01FA-7815-04 Regulator KA7815E TO-220 FAIRCHILD +15v 1 U100
01FA-7915-04 Regulator KA7915 TO-220 FAIRCHILD -9v 1 U101
2601-P817-00 Optocoupler PC817 DIP4 1 U103
2601-0202-00 Optocoupler LCR-0202 1 R43
03T1-Z48N-02 MOS Transistor IRFZ48N TO-220 6 Q113 Q114 Q115 Q116 Q117 Q118
2202-1602-05 Rectifier UF1602CT AKA 16/200V TO-220 2 D113 D114
2202-1620-05 Rectifier MUR1620CTA KAD 16A/200V TO-220 2 D115 D116
Miscellaneous
1380-0203-00 Temperature Switc
h
JUC-31F65℃ ±5℃ TO-220 1 RTH1
3000-INIT-02 Transformer
φ47 4:8:13:18 L1=L2=φ1.0*8*4TS
S1=S2=φ1.0*1*8TS S3=S4=φ1.0*4*13TS
S5=S6=φ1.0*1*18TS
1 L102
1401-0001-03 Fuse holder DIP 3PIN BXS3-09 1 for F100
1601-203G-00 Fuse DIP 20A/32V 3 F100
1404-0004-00 RCA 4 Jacks white red golden 1 RCA1
1413-0001-00 Phone Jack 6P4C RJ11 Black 1 JK1
1500-0400-01 Terminal JSZ4-32 POWER 1 CN100
1006-1010-10 inductor 100UH 1/2W 1 L11
05RN-3031-02 Thermal resistor 30K Φ5MM 1 RT200
1380-0209-00 Temperature Switc
h
DIP80℃±5℃ TO-220 1 TH100
1500-0300-01 Terminal JSZ3-31 1 CN200
1001-4711-10 inductor
8:8 470UH L1=φ0.6*1*8TS
L2=φ0.6*1*8TS CORE:OR(13*7*5)*2
1 L103
1005-5R03-10 inductor DIP 5UH Φ10*30MM 2 L1A L1B
1400-0001-16 Jack DIP 16PIN RJ45 2* 10P16C 1 CN1
1502-0504-00 Jack DIP Pitch 2.0MM 5PIN Bend 90 degree 1
LED BOARD
2004-0017-00 LBD φ3 white with blue light 8
2100-0036-05 FFC 5PIN 2.0mm UL1007 28AWG L=225mm 1
2000-0017-00 LED DIP Red with red light Φ3MM 2P 1 LED101
2004-0014-00 LED DIP Φ3.0MM Blue with blue light 1 LED100
0701-6102-02 Resistor SMD 1KΩ 1/2W ±5% 2010 2
2102-0153-02 FFC
2PIN UL1007 Red Black 28AWG
L=320mm soldering with 5mm
1
12
1300a Reference Series
