Part Number Qty Reference Designator
Description
LED BOARD
2102-0154-02 FFC
2PIN UL1007 Red Black 28AWG L=40mm
soldering with 5mm
1
1502-0504-00 Jack DIP Pitch 2.0MM 5PIN 弯90度 1
06S121046000 SMD Capacitor SMD 0.1uF/50V 0805 X7R ±10% 2 C1 C2
04PT-4148-01 Diode SMD 1N4148 DO-213AA 2 D1 D2
MECHANICAL
LS1AM0250401 Screw plating black zinc 2.5*4 4
LS1AY0301201 Screw PM3*12MM plating black zinc 1
LS1CJ0402507 Screw TA4*25MM plating 4 Accessory kit
KT-200021300 CAP red PVC RCA jack PVC material 2
KT-200012200 CAP white PVC RCA jack PVC material 2
LS5KP0300807 Screw 3*8MM (plating) 8
LS5KJ0301007 Screw 3*10MM (plating) 3
ZL-10037A-15 6.5PC Pole φ7*6.4+φ4.95*1.5mm nylon color 1
ZA-H00040100 REFsnap button φ7.5 M3.5*4 aluminum 4
DQ8069032084 Washer Φ6.9*Φ3.2*0.8MM M3 1
KG-100100500 snap button
T07-003-01 snap button φ11*φ14*10.8
black ABS
4
LS1AM0300607 Screw PM3*6(plating) 2
LS1AY0300452 Screw PM3*4.5MM plating white znic 2
LS1AA0301501 Screw PA3*15(plating black znic) 2
LS1AA0200501 Screw PA2*5(plating) 1
LS1FM0300011 Screw KM 3*6MM black znic 5
LS1FJ0200801 Screw KA2*8（platiing） 2
PL-L0002-000 Grounding GND-3 1
XN-10500-012 Knob ABS-757 black Ф10.5*9MM 3
XN-10500-011 Knob ABS-757black 11.7*Ф11MM red direction 1
JY297A22A001 Mica 97*22*0.1mm no hole 2
JY247A22A001 Mica 47*22*0.1mm no hole 4
CP-B00011400 Lens
40*10.8*5.7mm Pc material plastic grey
10C
1
SG-0016-2601 Top plate
360*227*62mm aluminium，H1-144silver
lacquer silk-screen
1
SR-1300-0117 Heatsink 325*216*58mm 1
XG-0017-2601 Bottom Plate
325*182*1.2mm H1-144silver lacquer
sick-screen
1
PL-L0007-000 Cliper 30*36*0.8mm 4
PL-L0006-000 Cliper 30*28*0.8mm 6
GD-600011400 Reflector
270*53.5*13mmblue clear PC material
plastic
1
GD-600010003 Acrylics board 264*48*4.0mm clear Acrylics 1
JY222A18A01X Mica 22*18*0.1MM 1
HG-0004-2601 Rear Plate
214*70*1.2mm H1-144silver paint silk-
screen
1
MK-0004-2601 Front Plate
214*70*1.2mm H1-144silver paint silk-
screen
1
1300a Reference Series
