OPTIONS
35
P90 P101 P110 P130
HP95 P150 P180 HP140
LUBRICATOR
SAFETY
WARNING: Ensure that the lubricator filler cap is re–tightened
correctly after replenishing with oil.
WARNING: Do not replenish the lubricator oil, or service the
lubricator without first making sure that the machine is stopped
and the system has been completely relieved of all air pressure
(Refer to
STOPPING THE UNIT
in the
OPERATING
INSTRUCTIONS
section of this manual).
CAUTION: If the nylon tubes to the lubricator are disconnected then
ensure that each tube is re–connected in its original location.
GENERAL INFORMATION
Oil capacity: 2 litres
Oil specification:
Refer to the
Tool Manufacturer’s Manual
.
OPERATING INSTRUCTIONS
COMMISSIONING
Check the lubricator oil level and fill as necessary.
PRIOR TO STARTING
Check the lubricator oil level and replenish as necessary.
MAINTENANCE
Check the lubricator oil level and replenish as necessary.
FAULT FINDING
FAULT CAUSE REMEDY
No oil flow.
Incorrect
connection.
Reverse the nylon tube
connections to the lubricator.
COLD START AID
SAFETY
Refer to the
SAFETY SECTION
in this manual.
GENERAL INFORMATION
The Cold start aid is fitted to machines to assist in starting the engine
in temperatures of between 0C and –10C.
OPERATING INSTRUCTIONS
STARTING THE UNIT
Refer to section 5
PRIOR TO STARTING
and
STARTING THE
UNIT
.
Follow the instructions given in section 5
STARTING THE UNIT,
depressing the
Cold Start Button
for 30 seconds immediately prior to
turning the keyswitch to position
III
(engine start position)
.
The Cold
Start indicator light will illuminate whilst the button is depressed.
MAINTENANCE
Refer to the
MAINTENANCE
section of this manual.
FAULT FINDING
Refer also to the
FAULT FINDING
section in this manual.
FAULT CAUSE REMEDY
Engine fails
to start.
Loose
connections
on the cold
start
harness/wiring
Check the connections and tighten
as necessary.
Engine fails
to start.
Cold start
relay faulty.
Replace the relay.
