24
6.3 Log and Diagnostic Records
log in to the Web page, click on the "Status >> Log" menu in the navigation tree to enter the "system log"
interface. Click the corresponding button to complete the log and diagnostic records download.
Figure 6-3 Diagnostic Log Function
VII. Description of panel indicator
7.1 Panel LED Indicator Description
Figure 7-1 Led Indicator Description
Equipment LED Light Description Table:
Status( Green)
Cellular( Wong)
Definition
Off
Off
No Power
