InMotion Explore V11Y - Page 8

6
PRODUCT FEATURES INTRODUCTION
Specication Item Argument
Basic Specs
Range（km) 120
Charging time（h) 6.6h with single charger；3.3h with dual chargers
Rated Power（KW) 2.5
Max.Power（KW) 7
Max.torque（N.M) 150
Max.speed（KM/H) 60
Max.slope（°） 40°
Suspension travel（mm） 85
Frame
Length*Width*Height（mm） 555*180*744
Net weight（kg） 30.4
Max. payload（kg） 120
IP ratings IPX6
Batte Pack
Rated capacity（Wh） 1423
IP ratings for batte IPX7
Rated voltage（V） 72.6
Sma BMS Overcharging protection, over-temperature protection, over-discharge
protection, overcurrent protection, sho circuit protection, oveoltage
protection, and etc.
Motor
Motor size 12inch
Tire size (Outer cover) 18*3.00
Tire pressure（BAR) 2.5BAR
IP ratings for motor IPX6
[1]: fully charged, 75 kg payload, 25°C, no wind, and cursing at the flat road in 25km/h.
[2]: fully charged, 75 kg payload, 25°C, no wind, at the flat road.
[3]: fully charged, 75 kg rider get the data through a large amount of tests.
[1]
[2]
[3]
