M O D E V A R e f e r e n c e M a n u a l P a g e 10 o f 16
6.1 MODEVA/Load Assembly Current Consumption Characteristics
Device
Peak Current Consumption
Logic Board (basic)
50mA
Logic Board w/ 1mW Radio
60mA
Logic board with IR transceiver
70mA
Capacitive Touch PCBA (02-7060)
10mA(n x 3.5mA) (logic board current plus the number of LEDs)
Load Assembly Relay Actuator
35mA
Load Assembly TRIAC Actuator
35mA
Load Assembly MOSFET Actuator
35mA
For example, a MODEVA assembly that
 uses the capacitive touch PCBA for a 6 input / output user interface,
 communicates wirelessly using the 2.4Ghz radio, and
 uses the MOSFET dimmer to actuate a load
would have a peak current consumption figured as follows:
Logic Board w/ 1mW Radio
60mA
=121mA (Peak Current Consumption)
Capacitive Touch PCBA (02-7060)
10mA(6 x 3.5mA)=31mA
MOSFET Actuator
30mA
The total DC load rating of a single actuator is 200mA. Therefore, a single actuator has 80mA remaining to
provide 12VDC power to S5-bus devices.
7 Load Specifications
7.1 Single gang installation
The following table provides load ratings at absolute maximum based on the load type in a single gang wall box.
Actuator
Ratings
Voltage
Frequency
Power / Amperes
Load Type
Relay Actuator
120-240 Vac
50/60 Hz
4.1 A
Resistive
120-240 Vac
50/60 Hz
4.1 A
General Purpose
120-240 Vac
50/60 Hz
500 W
Tungsten / ELV
120-240 Vac
50/60 Hz
250 VA
Electric Ballast
TRIAC Dimmer
120 Vac
60 Hz
2.9 A
Resistive
120 Vac
60 Hz
2.9 A
General Purpose
120 Vac
60 Hz
500 W
Tungsten / ELV
120 Vac
60 Hz
250 VA
Electronic Ballast
