Inncom Modeva - Multigang Installation; Multigang Installation Derating Chart; Actuator Ratings

M O D E V A R e f e r e n c e M a n u a l P a g e 11 o f 16
Actuator
Ratings
Voltage
Frequency
Power / Amperes
Load Type
MOSFET
Dimmer
120 Vac
60 Hz
2.9 A
Resistive
120 Vac
60 Hz
2.9 A
General Purpose
120 Vac
60 Hz
350 W
Tungsten / ELV
120 Vac
60 Hz
250 VA
Electronic Ballast
7.2 Multigang Installation
The MODEVA and Load Assembly comes in single, double and triple gang configurations; the double and triple
gang assemblies may be any combination of relay, switches, MOSFET Dimmer or TRIAC Dimmer. The table
below provides the derated output based on the configuration.
Actuator
Ratings
Voltage
Frequency
Power / Amperes
Load Type
TRIAC Dimmer
120 Vac
60 Hz
2.9 A
Resistive
120 Vac
60 Hz
2.9 A
General Purpose
120 Vac
60 Hz
400 W
Tungsten
120 Vac
60 Hz
250 VA
Electronic Ballast
MOSFET
Dimmer
120 Vac
60 Hz
2 A
Resistive
120 Vac
60 Hz
2 A
General Purpose
120 Vac
60 Hz
250 W
Tungsten
120 Vac
60 Hz
250 VA
Electronic Ballast
8 Multigang Installation Derating Chart
8.1 Actuator Ratings
Actuator
Ratings
TRIAC Dimmer
Voltage
Frequency
Power /
Amperes
Load Type
120 Vac
60 Hz
2.9 A
Resistive
120 Vac
60 Hz
2.9 A
General Purpose
120 Vac
60 Hz
400 W
Tungsten
120 Vac
60 Hz
250 VA
Electronic Ballast
MOSFET
Dimmer
Voltage
Frequency
Power /
Amperes
Load Type
120 Vac
60 Hz
2 A
Resistive
120 Vac
60 Hz
2 A
General Purpose
