Appendix II 47
Unknown Fiber Type
Dust on the ber surface. Re-prepare the ber.
Different ber types on two sides. AUTO mode is not applicable in
this case; select a suitable splice
mode to redo splicing.
The ber is a non-standard ber. AUTO mode can only detect
standard SM, MM, NZ bers.
Fiber Clad Over Limit
Fiber edge is not located in the
camera range.
Adjust the ber position; perform
[Motor Calibration].
Fiber Endface Gap Wrong
[Overlap] is too much. Adjust [Overlap] parameter.
Motor is not calibrated. Perform [Motor calibration].
Fibers Mismatch,
Continue?
Different ber types on two sides. It may result in large splice loss
if you continue to splice. Please
use the proper splice mode
corresponding to the bers.
Cleave Angle Over Limit
Bad ber endface. Check the condition of the ber
cleaver. If the blade is worn,
rotate the blade to a new position
or change a new one, and then
re-prepare the bers.
[Cleave Angle Limit] is set too low. Increase the [Cleave Angle Limit]
to an adequate limit (standard:
3.0˚).
Core Angle Over Limit
[Core Angle Limit] is set too low. Increase the [Core Angle Limit] to
an adequate limit (standard: 1.0˚).
Dust or dirt on the V-groove or
ber holders.
Clean the V-groove and ber
holders. Prepare the bers and
re-load them.
Fiber Axis Align Failed
Too large axial offset (>4.0㎛).
Re-prepare the bers.
The motor is not calibrated. Perform [Motor calibration].
