Version 1.0 Preliminary 7
VIRTUAL BUTTON MAPPING
Developers-Note3: The Most Significant Bit (data bit 7) is functionally defined as the button press
bit and is set by the VRC prior to transmission of the scancode to the spitfire. To avoid any
confusion this table along with the buttons.txt and ISI###.dat files all do not have the MSB set, but
when the code is transmitted the MSB is always set. If you do not set the MSB the spitfire will not
respond to the command or will misinterpret the command.
Buttons that Transmit IR
Function CODE Class
0 00h channel
1 01h channel
2 02h channel
3 03h channel
4 04h channel
5 05h channel
6 06h channel
7 07h channel
8 08h channel
9 09h channel
Enter 0Ah channel
Mute 0Bh volume
Volume up 0Ch volume
Volume down 0Dh volume
Channel up 0Eh channel
Channel down 0Fh channel
Rewind 10h transport
Play 11h transport
Fast Forward 12h transport
Record 13h transport
Stop 14h transport
Pause 15h transport
Power 16h power
Previous 17h channel
Input 18h PIP
Display 19h setup
Menu 1Ah setup
Select 1Bh Setup
Navigate up 1Ch Setup
Navigate down 1Dh Setup
Navigate left 1Eh setup
Navigate Right 1Fh setup
Exit 20h setup
Guide 21h setup
10+ 22h channel
TITLE 23h
Sleep 24h power
Yellow Square 25h channel
Blue Circle 26h channel
Red Triangle 27h Channel
PIP 28h PIP
PIP Ch+ 29h PIP
PIP CH- 2Ah PIP
PIP move 2Bh PIP
PIP swap 2Ch PIP
Function CODE Class
Page up 2Dh channel
Page down 2Eh channel
Power off 2Fh power
XIR48 30h none
XIR49 31h none
XIR50 32h none
XIR51 33h none
XIR52 34h none
XIR53 35h none
XIR54 36h none
XIR55 37h none
XIR56 38h none
XIR57 39h none
XIR58 3Ah none
XIR59 3Bh none
XIR60 3Ch none
XIR61 3Dh none
XIR62 3Eh none
XIR63 3Fh none
Control Buttons
Function CODE Type
Program 40h Setup
AUX 41h Slot
TV 42h Slot
VCR 43h Slot
DVD 44h Slot
Audio 45h Slot
CBL/SAT 46h Slot
Search 47h Setup
Learn 48h Setup
F1 49h Macro
F2 4Ah Macro
F3 4Bh Macro
F4 4Ch Macro
Smart Source ON 4Dh Setup
Smart Source Off 4Eh Setup
Toggle Smart Source 4Fh Setup
IR repeat 0 50h Setup
IR repeat 1 51h Setup
IR repeat 2 52h Setup
IR repeat 3 53h Setup
IR repeat 4 54h Setup
IR repeat 5 55h Setup
IR repeat 6 56h Setup
