Version 1.0 Preliminary 8
Function CODE Type
IR repeat 7 57h Setup
Erase Learned button 58h Setup
Write EEPROM 59h Setup
Read EEPROM 5Ah Setup
Clear EEPROM 5Bh Setup
Revision number 5Ch Setup
Device number 5Dh Setup
Number of learned buttons 5Eh Setup
Erase Selected Device 5Fh Setup
Enable Punch-Thru 60h Setup
Disable Punch-Thru 61h Setup
Size EEPROM 62h Setup
Status Byte from Spitfire to Host
Response byte CODE
Invalid Scan Code 31h
Invalid Device Code 32h
Search Exhausted 33h
Slot Empty 34h
Program Abort 35h
IR Xmit complete 36h
Invalid IR type 37h
Power-On-Reset 38h
Auto Search 39h
No Learn button specified 3Ah
No Learn IR detected 3Bh
Learn Started 3Ch
Brand Search 3Dh
Non-Learnable button 3Eh
Learn analysis Error 3Fh
Send Start Address Lo 11h
Response byte CODE
Send Start Address Hi 12h
Send End Address Lo 13h
Send End Address Hi 14h
Read Complete 15h
Write Complete 16h
Start Write 17h
Read/Write Error 18h
Memory Full 19h
EEPROM NG 1Ah
EEPROM SIZE 128 1Bh
EEPROM SIZE 64 1Ch
Erase Complete 1Dh
Search Exhausted 1Eh
Abort Learn 2Ah
IR Xmit from AUX slot 40h
IR Xmit from TV Slot 41h
IR Xmit from VCR slot 42h
IR Xmit from DVD slot 43h
IR Xmit from AUD slot 44h
IR Xmit from CBL/SAT slot 45h
IR Xmit Macro End-Of-String 10h
IR Xmit Macro End Of Macro 1Fh
Xmit Macro Delay 46h
Indicator Flash 0 A0h
Indicator Flash 1 A1h
Indicator Flash 2 A2h
Indicator Flash 3 A3h
Indicator Flash 4 A4h
Indicator Flash 5 A5h
Indicator Flash 6 A6h
Indicator Flash 7 A7h
Indicator Flash 8 A8h
Indicator Flash 9 A9h
