Inogen One G3 Guide

To change the columns on your Inogen One G3, first:
Remove the battery from the Inogen
One® G3 concentrator.
Turn the Inogen One® G3 over so that is standing
in the upside down position where the display
panel is facing down and the bottom of the
Inogen One® G3 is facing up.
Remove column by pressing the latch
button with thumb or finger.
While still holding the button
open, slide the column (metal
tube) out by pushing with the
column tool.
While holding the button
open, insert the column tool
underneath the opposite side
of the column (metal tube) with
other hand.
Remove the column completely
from the Inogen One® G3.
And then repeat steps 5 - 7
for the other column.
For the column installation, remove
dust caps of new column. Make sure
there is no dust or debris where the
dust caps were located.
Insert column into the Inogen One® G3
concentrator. Do not leave the column
exposed; it should be inserted into the
Inogen One® G3 as soon as the dust caps
have been removed.
Continues on back
Push the column into the device such that the
column is fully seated into the Inogen One® G3
concentrator. The spring loaded latch button
should fully return to the locked and closed position.
Repeat steps 8-10 to install the other column.
PMS 661 main color/651 swish
3
4
5
7
6
8
9
10
11
www.inogen.com
1
2
Remove the Inogen One® G3 concentrator from
the carry bag.
Turn off the Inogen One® G3 concentrator by pressing the
power button to shut down the device.
NOTE Column change instructions are only to be used when maintenance is
required and are not intended for practice purpose.
