To change the columns on your Inogen One® G5, first:
Remove the battery from the
Inogen One® G5 concentrator.
Place the Inogen One® G5 concentrator
on its side so that the underside is visible.
The metal column assembly can be seen on
one side of the device.
Unlock the column assembly by
pushing the latch button away
from the columns.
Remove the columns
completely from the Inogen
One® G5. Both columns are
removed as one piece.
While holding the button open,
slide the column assembly out
of the device by pulling on the
column pull handle.
Remove dust caps of new
coulmn assembly. Make sure
there is no dust or debris
where the dust caps were
located.
Insert column assembly into the
Inogen One® G5 concentrator.
Do not leave the column ends
exposed; column assembly should
be inserted into the Inogen One® G5
as soon as the dust caps have been
removed.
Push the column assembly into the device
such that the columns are fully seated
into the Inogen One® G5 concentrator.
The spring loaded latch button should
fully return to the closed position.
Continues on back
Connect the AC power supply cord to the Inogen
One® G5 and plug the power supply AC cord into an
electrical outlet. Do Not Power on the Inogen One® G5
concentrator.
3
4
5
7
8
9
10
11
1
2
Remove the Inogen One® G5 concentrator from
the carrying case (if attached).
Turn off the Inogen One® G5 concentrator by pressing the
power button to shut down the device.
NOTE Column change instructions are only to be used when maintenance is
required and are not intended for practice purpose.
6
Press and hold the plus
(+) and (-) minus buttons
for 5 seconds. The screen
will display “sieve reset”
message. Release
buttons once message is
displayed on screen.
Press the alert/bell button
once and screen will
display "sieve reset
success." Press the power
button to turn on the
Inogen One® G5, and use
normally.
12
13
