INOKIM REAR FLAT TIRE REPAIR
PLACING THE MOTOR WHEEL BACK
Slide back Motor.
Check right order
of washers at both
sides!
1
Note inner washers
are in place
2
Safety extension lock
of the washer must
enter this slot on both
sides of motor hinge
Note external
washer with lug is in
correct slot!
3
