INOKIM QUICK 3 - Plastic Cover Assembly: Alignment; Plastic Cover Assembly: Sliding; Plastic Cover Assembly: Securing; Aluminum Profile Check

36
INOKIM REAR FLAT TIRE REPAIR
Align plastic cover
lines to INOKIM
body lines
1
The body
construction rail is
showing through the
slot of the plastic
Slide in plastic
cover
Both corners of
Aluminium and
plastic should be
aligned
Align plastic cover
hole with 4mm
hole on INOKIM
body and screw it
PLASTIC COVER ASSEMBLY
2
3
Note that aluminium
the hole!
