10 11
FOLDING
CHARGING
switch
Charging
socket
Open the rubber cover under the frame and
connect the charger to the socket.
1
Charging Indication:
RED light - Battery charging
GREEN light - Charging complete
2
Attention! Read battery safety and maintenance sections
carefully before charging and mounting the battery.
Open 11 screws to reveal the battery
Battery:
• Do not operate motor while charging!
• Do not store INOKIM for long terms (more than
two months) with fully charged battery
• From time to time discharge and fully charge the
battery
52V|13Ah 52V|16Ah
FOLDING
To fold the handlebars, push the RED secure sleeves aside
1
To fold QUICK
4
, release the RED SAFETY LOCK
push the steering bar firmly forward while at the same time
using your foot to push the RED pedal down to release the
FOLDING MECHANISM
2
3
Push
down
Unlock
To fold QUICK
4
, repeat unfolding actions in reverse order:
Push
simultaneously
and release
Click
