1 Product Information
- 22 -
1.4.3 SV660P/N
Frame Size 40/60/80(50W-1kW)
Table 1-16 Cables for terminal-type (Z series) motors with front cable outlets
Cable Type
Cable Length (m)
3.0 5.0 10.0
Power cable (without brake) S6-L-M107-3.0 S6-L-M107-5.0 S6-L-M107-10.0
Power cable (with brake) S6-L-B107-3.0 S6-L-B107-5.0 S6-L-B107-10.0
Absolute encoder cable S6-L-P124-3.0 S6-L-P124-5.0 S6-L-P124-10.0
Incremental encoder cable S6-L-P114-3.0 S6-L-P114-5.0 S6-L-P114-10.0
Table 1-17 Cables for terminal-type (Z series) motors with rear cable outlets
Cable Type
Cable Length (m)
3.0 5.0 10.0
Power cable (without brake) S6-L-M108-3.0 S6-L-M108-5.0 S6-L-M108-10.0
Power cable (with brake) S6-L-B108-3.0 S6-L-B108-5.0 S6-L-B108-10.0
Absolute encoder cable S6-L-P125-3.0 S6-L-P125-5.0 S6-L-P125-10.0
Incremental encoder cable S6-L-P115-3.0 S6-L-P115-5.0 S6-L-P115-10.0
Table 1-18 Cables for terminal-type (Z series) motors with front cable outlets (drag chain)
Cable Type
Cable Length (m)
3.0 5.0 10.0
Power cable (without brake) S6-L-M107-3.0-T S6-L-M107-5.0-T S6-L-M107-10.0-T
Power cable (with brake) S6-L-B107-3.0-T S6-L-B107-5.0-T S6-L-B107-10.0-T
Absolute encoder cable S6-L-P124-3.0-T S6-L-P124-5.0-T S6-L-P124-10.0-T
Incremental encoder cable S6-L-P114-3.0-T S6-L-P114-5.0-T S6-L-P114-10.0-T
Table 1-19 Cables for terminal-type (Z series) motors with rear cable outlets (drag chain)
Cable Type
Cable Length (m)
3.0 5.0 10.0
Power cable (without brake) S6-L-M108-3.0-T S6-L-M108-5.0-T S6-L-M108-10.0-T
Power cable (with brake) S6-L-B108-3.0-T S6-L-B108-5.0-T S6-L-B108-10.0-T
Absolute encoder cable S6-L-P125-3.0-T S6-L-P125-5.0-T S6-L-P125-10.0-T
Incremental encoder cable S6-L-P115-3.0-T S6-L-P115-5.0-T S6-L-P115-10.0-T
Table 1-20 Cables for lead wire-type (Z-S series) motors
Cable Type
Cable Length (m)
3.0 5.0 10.0
Power cable (without brake) S6-L-M100-3.0 S6-L-M100-5.0 S6-L-M100-10.0
