G SERIES PILOT’S GUIDE .
INSIGHT INSTRUMENT CORPORATION BOX 122, FORT ERIE, ONTARIO, L2A 5M6
5
Guide To The G Series Screens
The instrument has two control knobs that operate combination rotary and push button switches.
The top knob in general controls screen selection while the bottom knob controls items within the given screen.
Each screen assigns its own functional needs to the controls that may change depending on context.
A screen may also label the controls with guidance information like “Push to exit”.
Some of the many revolutionary new features of the G3-4 system include:
Engine vibration measurement and analysis.
Specific functionality for safe Lean of Peak operation with no detonation
Oil Temperature and Pressure
Manifold Pressure, Fuel Flow and RPM
OAT
Carburetor and Alternator Temperature
Buss Voltage
Specialized analysis for propeller balance, turbulence and even landing shock.
Integrates and logs data from G3-4, TAS Air Data and GPS for the complete picture.
SD Card stores all engine, air, winds aloft and fuel data (No more lost data).
Entire aircraft life history directly on SD card in PC compatible form.
NOTE:
To check brightness use incandescent light source to shine on GSeries instrument face.
LED and fluorescent will not work because of the lack of infrared in beam.
