www.insigniaproducts.com
11
NS-HF2007
STEP 4:
You need:
Using cam locks
When you insert a cam lock, position the open end of the lock toward the cam screw, then insert the cam screw into the
cam lock opening.
1 Insert four cam locks (DD) into the long lower shelf (D).
2 Insert the cam screws on the divider panels (B and C) into the cam locks on the long lower shelf, then tighten the locks
with a Phillips screwdriver.
DD Small cam lock (4)
B Left divider
panel (1)
C Right divider
panel (1)
D Long lower shelf (1)
Phillips screwdriver
DD
DD
DD
