Insignia NS-HF2007 - Assembly Guide; Step 1: Initial Rail Assembly

www.insigniaproducts.com
7
NS-HF2007
Needed tool
Assembly instructions
STEP 1:
You need:
1 Separate the CL and CR parts of the rail assembly (BB) from the DL and DR parts and set the DL and DR parts aside for
use in another step.
2 Insert three 3 × 12 mm screws (AA) into the correct holes on the CL and CR parts of the rail assembly (BB).
3 Align the CL part of the rail assembly (BB) to the inside of the left divider panel (B). Make sure that the wheel on the
assembly is at the back of the panel.
4 Tighten the screws with a Phillips screwdriver.
5 Align the CR part of the rail assembly (BB) to the inside of the right divider panel (C). Make sure that the wheel on the
assembly is at the back of the panel.
Phillips screwdriver
CR
DR
DL
CL
AA 3 × 12 mm
screw (6)
BB Left and right rail assembly (2)
B Left divider
panel (1)
C Right divider
panel (1)
Phillips screwdriver
AA AA AA
BB
AA
AA
AA
CL
