www.insigniaproducts.com
9
NS-HF2007
STEP 2:
You need:
1 Insert two cam screws (CC) into the holes on the left divider panel (B), then tighten the screws with a Phillips
screwdriver.
2 Insert two cam screws (CC) into the holes on the right divider panel (C), then tighten the screws with a Phillips
screwdriver.
CC Cam screw (4)
B Left divider
panel (1)
C Right divider
panel (1)
Phillips screwdriver
CC
CC
CC
CC
