4
www.insigniaproducts.com
Introduction
Congratulations on your purchase of a high-quality
Insignia product. Your NS-L22X-10A represents the
state of the art in LCD TV design and is designed for
reliable and trouble-free performance.
Installing a wall-mount
bracket
To install a wall-mount bracket:
1 Remove the three screws that secure the stand
to your TV.
2 Remove the stand.
3 Insert and lock the standoff screws (provided)
into the lock holes of the VESA mount.
4 Attach the wall-mount bracket with M4 screws
(not included).
Warning
This apparatus is intended to be supported by UL
Listed wall mount bracket.
Warning
These servicing instructions are for use by qualified
service personnel only. To reduce the risk of hazards,
do not perform any servicing other than that
contained in the operating instructions unless you
are qualified to do so.
3.94" (100 mm)
3.94" (100 mm)
NS-L22X-10A_09-0222_MAN_V1_English.book Page 4 Thursday, April 2, 2009 12:14 PM
