STEP 3 - Option 2: Attaching rear-mount speakers with key-hole
slots
1 Attach the L Bracket (10) to the top pole (02) with an M5 x 15 mm screw (11),
with the speaker wire slot arranged as shown. Tighten securely.
You’ll need
10 L bracket (2)
(11) M5 × 15 mm
screw (2)
05 Adjusting nut (2)
(06) 1/4-20 × 12 mm
screw (2)
Speaker wire slot
