Inspire CR 2 - Assembly Instructions

132
133
134
26
132
133
134 24
PAGE 7
Step 1
Attach and tighten the Rear Stabilizer Tube Assembly (26) to the frame (24) using 4 – A
M10x20 Socket Head Screws (132), 4 – M10 Spring Washers (133), and 4 – M10
Curved Washers (134).
