M2 PARTS & HARDWARE LIST
Item Parts Description Qty
Qty Rec'd
Item Hardware Description Qty
Qty Rec'd
1 Base Beam 1 1 Bolt, 1/4-20 x 3/8" L
(Phillips head)
1
2 Rear Base 1 2 Bolt, 1/4-20 x 3" L
(Button Head)
1
3 Backing Plate 1 3 Bolt, 5/16-18 x 1-1/4" L
(Shoulder)
3
4 Foot Plate 1 4 Bolt, 3/8x16 x 1" L
(Flat Head)
8
5 Main Upright 1 5 Bolt, 3/8-16 x 1/2" L
(Button Head)
2
6 Top Beam Plate 2 6 Bolt, 3/8-16 x 1" L 6
7 Press Arm Mount 1 7 Bolt, 3/8-16 x 1 3/4" L 7
8 Press Arm Cover Plate 1 8 Bolt, 3/8-16 x 2" L 4
9 Press Arm Bearing Assembly 2 9 Bolt, 3/8-16 x 2 1/2" L 1
10 Press Arm Assembly 1 10 Bolt, 3/8-16 x 2 3/4" L 2
11 Backpad Tilt Frame 1 11 Bolt, 3/8-16 x 3" L 5
12 Lat Bar Holder 2 12 Bolt, 3/8-16 x 3 3/4" L 8
13 Guide Rod 2 13 Bolt, 3/8-16 x 4" L 6
14 Shroud Plate 1 14 Bolt, 3/8-16 x 4 3/4" L 1
15 Shroud Plate Assembly 1 15 Bolt, 3/8-16 x 5" L 1
16 Floating Pulley Plate 2 16 Bolt, 3/8-16 x 5 3/4" L 1
17 Floating Pulley Bracket 1 17 Bolt, 1/2-13 x 6" L 1
18 Top Weight/Selector Stem 1 18 Setscrew, 1/4-20 x 3/16" long 2
19 Weight Stack Riser 2
20 Weight Stack Number 1 19 1/4" Washer 1
21 Rubber Donut 2 20 3/8" Washer 65
22 Roller Tube 3 21 3/8" Washer, small OD 6
23 Covered Foam Roller 6 22 1/2" Washer 2
24 Aluminum Endcap 6
25 Large Plastic Washer 6 23 1/4-20 Flat Head Nut 1
26 Seat Stem 1 24 5/16-18 Locknut 3
27 Seat Base 2 25 3/8-16 Locknut 36
28 Head Pad 1 26 1/2-13 Locknut 1
29 Upper Cable 1
30 Middle Cable 1 27 Spacer Tube, 3" Long 1
31 Lower Cable 1 28 Step Spacer, 1" Long 8
32 D handle/Ab Strap 2 29 Step Spacer, 1/2" Long 2
33 Ankle Strap 1 30 Barrel Spacer, 1" Long 2
34 Revolving Aluminum Lat Bar 1 31 Barrel Spacer, 5/8" Long 2
35 Revolving Aluminum Curl Bar 1
36 Fabric Shroud 1 32 Cable Adapter 1
37 Guide Rod Lube 2 33 "U" Bracket Cable End 3
38 Touch-up Paint 1 34 Cable Ball 3
35 Spring Clip 4
39 3 1/2" Pulley 14 36 Chain 1
40 4 1/2" Pulley 2 37 Weight Pin 1
41 4 1/2" Wide Pulley 1 38 3 mm Wrench 1
39 5 mm Wrench 1
40 6 mm Wrench 1
