1 Main Frame, Lat Station 1 57 4 1/2" Pulley 2
2 Main Upright, Press Arm 1 58 Small Pulley, Leg Extension 2
3 Lat Seat Frame 1 59 3 1/2" Pulley 25
4 Seat Base Frame 1 60 Press Arm Exercise Placard 1
5 Preacher Curl Stem 1 61 Cable Ball 4
6 Foot Rest Assembly 1 62 "U" Bracket Cable End 4
7 Seat Stem Assembly 1 63 Floating Pulley Bracket 1
8 Back Pad Mount 1 64 Press Arm Cover Plate 1
9 Upper Shroud Mount Bracket 2 65 Lat Exercise Placard 1
10 Double D Low Row Handle Mount 1 66 Press Arm Bearing Assembly 2
11 Lower Pulley Mount 1 67 Rubber Donut 4
12 Press Arm Mount 1 68 Placard Hanger Bracket Assy 4
13 Press Arm Assembly 1 69 Large Plastic Washer 4
14 Back Pad Support Frame 1 70 Weight Plate 40
15 Leg Extension Assembly 1 71 Adjustment Bumper 1
16 Double D Low Row Handle 1 72 Cable Adapter 2
17 Revolving Aluminum Lat Bar 1 73 Corner Bracket 1
18 Revolving Aluminum Curl Bar 1 74 Flat Head Nut, M6 4
19 Calf Block Attachment Arm 1 75 Button Head Bolt, M6*15 4
20 Floating Pulley Bracket Assembly 1 76 Weight Pin Lanyard Assembly 2
21 Adjustable Stop 2 77 Top Weight/Selector Stem Assembly 2
22 Top Beam Plate, Press Arm 2 78 Spring Clip 4
23 Top Beam Plate, Lat Station 2 79 Flat Washer, M8 8
24 Pulley Bracket 1 80 Washer, Φ25.4*Φ10*2 14
25 Barrel Spacer, 1" long 1 81 Locknut, M8 4
26 Lower Guide Rod Mount 2 82 End Cap, Black Plastic 2
27 Cam Plate 1 83 Flat Head Bolt, M10*25 6
28 Floating Pulley Plate 4 84 Button Head Bolt, M5*12 1
29 Swivel Pulley Assy, Lat Station 1 85 Hex Nut, M12 2
30 Calf Raise Block 1 86 Flat Washer, M10 157
31 Shroud Plate Assembly 2 87 Flat Washer, M12 7
32 Shroud Plate 2 88 Curved Washer, M10 4
33 Shroud Bracket 4 89 Thin Locknut, M12, h=8mm 1
34 Preacher Curl Pad 1 90 Locknut, M10 76
35 Seat Pad 3 91 Locknut, M12 3
36 Small Covered Foam Roller 2 92 Button Head Bolt, M8*25 4
37 Thigh Pad 2 93 Hexagon Bolt, M10*100 7
38 Large Covered Foam Roller 4 94 Hexagon Bolt, M10*45 22
39 Covered Foam Roller with tube insert 2 95 Button Head Bolt, M10*20 2
40 Press Arm Lower Cable 1 96 Hexagon Bolt, M10*50 4
41 Leg Extension Cable 1 97 Hexagon Bolt, M10*95 12
42 Press Arm Middle Cable 1 98 Hexagon Bolt, M12*95 2
43 Press Arm Upper Cable 1 99 Hexagon Bolt, M12*110 1
44 Lat Lower Cable 1 100 Hexagon Bolt, M10*105 3
45 Lat Upper Cable 1 101 Hexagon Bolt, M10*110 1
46 Step Spacer, 1" long 10 102 Hexagon Bolt, M10*70 13
47 Step Spacer, 15mm long 2 103 Flat Head Bolt, M10*70 2
48 Leg Extension Cam Assembly 1 104 Hexagon Bolt, M10*60 4
49 Plastic Spacer Tube 2 105 Hexagon Bolt, M10*35 4
50 Aluminum Endcap 6 106 Hexagon Bolt, M10*20 15
51 Guide Rod 4 107 Hexagon Bolt, M12*150 1
52 Shroud Plate Spacer 2 108 Hexagon Bolt, M10*25 6
53 Shroud Plate Connector Pin 12 109 Flat Head Screw, M6 4
54 Fabric Shroud 2 110 Hex Key Wrench, 6mm 1
55 D Handle Strap 2 111 Hex Key Wrench, 5mm 2
56 Flat washer, M5 1 112 Hex Key Wrench, 4mm 1
113 Thin Locknut, M10，h=8mm 4
