Inspire SCS-202 - PARTS AND HARDWARE

PARTS AND HARDWARE
PAGE 2
Rev111514
Item
Parts Description SCS-002 Box Qty
Evs p/n Item Hardware in SCS-002 Box Qty Evs p/n
1 Main Upright 4 1 Bolt, M8 x 20 4
2 Base Beam, Left 1 2 Bolt, M10 x 25 (Blue dot) 2
3 Base Beam, Right 1 3 Bolt, M10 x 25 16
4 Weight Stack Mount 1 4 Bolt, M10 x 100 (Blue dot) 4
5 Base Beam Bracket 2 5 Bolt, M10 x 105 12
6 Top Beam, Right 1 6 Bolt, M10 x 110 8
7 Top Beam, Left 1 7 Bolt, M10 x 125 4
8 Pull-Up Cross Brace 1
9 Rear Cross Brace 1 7 M8 Washer 4
10 Weight Racks 4 8 M10 Washer 70
11 Plastic End Cap 8
12 Safety Bars 2 9 M10 Locknut 32
13 Touch-up Paint 1
Item
Parts Description SCS-202 Box
Qty
Evs p/n
Item
Hardware in SCS-202 Box
Qty
Evs p/n
1 Right Top Cable Column Mount 1 1 Bolt, M6 x 12 (Button Head) 6
2 Left Top Cable Column Mount 1 2 Bolt, M6 x 35 (Button Head) 6
3 Top Weight Stack Mount 1 3 Bolt, M8 x 25 2
4 Lat Attachment 1 4 Bolt, M10 x 25 2
5 Lat Attach Bracket, Upper 1 5 Bolt, M10 x 35 2
6 Lat Attach Bracket, Lower 1 6 Bolt, M10 x 45 5
7 Pull Up Bar 1 7 Bolt, M10 x50 2
8 Shroud Plate Spacer 2 8 Bolt, M10 x 55 (Blue dot) 2
9 Shroud Plate Assembly 2 9 Bolt, M10 x 60 (Button Head) 2
10 Shroud Mount Plate 2 10 Bolt, M10 x 60 (Blue dot) 4
11 Shroud Mount Bracket 4 11 Bolt, M10 x 60 4
12 Guide Rod 4 12 Bolt, M10 x 70 2
13 Rubber Donut 4 13 Bolt, M10 x 95 (Button Head) 1
14 Weight Stack Riser 4 14 Bolt, M10 x 95 4
15 Selector Stem / Top Weight 2 15 Bolt, M10 x 100 2
16 Top Weight Pulley Assy. 2 16 Bolt, M10 x 105 1
17 Weight Stack Shroud Mount 2 17 Bolt, M10 x 155 2
18 Row Pulley Mount 1 18 Bolt, M12 x 25 1
19 Lower Right Cable Column Mount 1 19 Bolt, M12 x 30 2
20 Lower Left Cable Column Mount 1
21 Pulley, 3 1/2" Diameter 8 20 M6 Flat Washer 6
22 Floating Pulley Assembly 2 21 M8 Flat Washer 4
23 Floating Pulley Assy w/ Guide Bushing 2 22 M10 Flat Washer 56
24 Cable Column 2 23 M12 Flat Washer 4
25 Cable Column Slider 2
26 Cable Anchor Plate 2 24 M6 Flat Head Nut 6
27 Upper Cable 2 25 M6 Locknut 6
28 Row Cable 2 26 M8 Locknut 2
29 Lower Cable (“U” End) 2 27 M10 Locknut 28
30 Guide Cable 2 28 M12 Locknut 2
31 Exercise Placard 1
32 D handle / Ab Strap 2 29 1/2” Step Spacer 6
33 Ankle Strap 1 30 Cable Ball 6
34 4 Ring “D” Handle 2 31 “U” Bracket Cable End 6
35 Pull-Up Assist Assy. 1 32 Spring Clip 6
36 Guide Rod Lube 2 33 Weight Pin 2
37 Touch-up Paint 2 34 Shroud Plate Connector Pin 12
35 4 mm Hex Key 1
36 5 mm Hex Key 2
37 6 mm Hex Key 1
