6-EN
1 - Bracket For Ceiling Mount
2 - Photosensor Twilight switch for IR LEDs
3 - Infrared LED for Night vision - 12 IR-LEDs ( @ 850nm)
4 - Lens Wide-angle (focal length: 4.3mm / eld of view: ~ 90º dia.)
5 - PIR Detector Integrated passive infrared (PIR) motion detector
6 - Microphone For noise detection / audio rec.
7 - MicroSD Card Slot Slot for MicroSD/SDXC cards (max. 128GB - 16GB included)
- inside the camera -
8 - Reset Press 15-20 seconds for reset
9 - Network LED O: No Power / No signal, Flashing: Network Signal
10 - Network Port RJ45 LAN port / connector for Cat5e LAN cable or higher
11 - Power Connector For included 12V / 1A power supply
4.3. Camera Tools
In the delivery content, you will nd 3 tools for loosening the camera bracket,
opening the camera dome from the back to access the cables, and opening the
camera from the glass front to adjust the lens.
Alley Key
