Go to http://install.instar.com
7-EN
The wrench tool is to be used for opening the cable nut at the back of the dome
casing. You can use this tool to access the cable inside the casing. In case you
want to place the cable through a wall, you can unplug the cables from the board
and take them out through the cable hole. Please do it with special caution in
order not to damage any wires.
Wrench
Glass Front Tools
In rare cases, you may need to adjust the lens focal. We provide also tools for
you to open the the glass front.
First, please use the metal tool to carefully open the metal ring that is xed on
top of the glass through the holes. Then you can use the rubber tool to lift up the
glass front as shown in below instruction.
To Next Page
