Integra DHC-80.2B Service Manual

156/157 PAGE
P8302 SOCKET YKF45-7037V 1 25053253R3
P8321 SOCKET YKF45-7037V 1 25053253R3
P8341 SOCKET YKF45-7037V 1 25053253R3
P8352 SOCKET YKF45-7037V 1 25053253R3
P8601 SOCKET YKF45-7037V 1 25053253R3
P8611 SOCKET YKF45-7037V 1 25053253R3
P8621 SOCKET YKF45-7037V 1 25053253R3
P8631 SOCKET YKF45-7037V 1 25053253R3
P8641B SOCKET FX16-31S-0.5SH 1 25053365R2 N
P8702 SOCKET NSCT-9P2472 1 25052575R2
P8705 SOCKET IMSA-9618S-04A 1 25053329R2
P8705 or SOCKET 04FMN-SMT-A-TF ( 1) 25052821R2
U0091 FRONT HDMI/USB PC BOARD AS BAHDM-0291-1B
1
1B2345291-1B
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D3300 C-DIODE KDS4148U 1 223283R2 <B MDD, MMA>
D3300 or C-DIODE 1SS352 ( 1) 223234R2 <B MDD, MMA>
D3301 C-DIODE KDS4148U 1 223283R2 <B MDD, MMA>
D3301 or C-DIODE 1SS352 ( 1) 223234R2 <B MDD, MMA>
D8861 C-DIODE KDS4148U 1 223283R2 <B MDD, MMA>
D8861 or C-DIODE 1SS352 ( 1) 223234R2 <B MDD, MMA>
D8862 C-DIODE KDS4148U 1 223283R2 <B MDD, MMA>
D8862 or C-DIODE 1SS352 ( 1) 223234R2 <B MDD, MMA>
Q3300 IC TPD2E001DRLR 1 22242589R2 <B MDD, MMA>
Q8861 IC TMDS141RHARG4 1 22242586R2 <B MDD, MMA>
[TRANS COIL]
L8861 CORE BLM18PG181SN1D 1 2350005R1 <B MDD, MMA>
[CAPACITOR]
C3302 C-FILM C ECHU16V-104J 1 373041044R2 <B MDD, MMA>
C3303 C-FILM C ECHU16V-104J 1 373041044R2 <B MDD, MMA>
C3304 C-CERA C CK725F1A-105Z1 1 332181050R1 <B MDD, MMA>
C8861 C-FILM C ECHU16V-104J 1 373041044R2 <B MDD, MMA>
C8863 C-CERA C CK725F1A-105Z1 1 332181050R1 <B MDD, MMA>
C8864 C-CERA C CK725B1H-102K1 1 332101025R1 <B MDD, MMA>
C8869 C-CERA C CK725F1A-105Z1 1 332181050R1 <B MDD, MMA>
