Integra DHC-80.2B Service Manual

23/157 PAGE
RL5109 RELAY NRL-2P2A-DC12-178 1 25065664
RL5111 RELAY NRL-2P2A-DC12-178 1 25065664
U002 U0020+U0021+U0022 BAAF-0242-1E *
1
1B234542-1E N
<B MDD>
U0020 BALANCE INPUT PC BOARD AS BAAF-0242-1E
1
1B2345242-1E
N <B MDD>
U0021 PRIMARY POWER SUPPLY PC BOARD AS BAPS-0243-1E
1
1B2345243-1E
<B MDD>
U0022 INLET PC BOARD AS BAPS-0244-1E
1
1B2345244-1E
<B MDD>
U002 U0020+U0021+U0022 BAAF-0242-1F *
1
1B234542-1F N
<B MMA>
U0020 BALANCE INPUT PC BOARD AS BAAF-0242-1F
1
1B2345242-1F
N <B MMA>
U0021 PRIMARY POWER SUPPLY PC BOARD AS BAPS-0243-1F
1
1B2345243-1F
<B MMA>
U0022 INLET PC BOARD AS BAPS-0244-1F
1
1B2345244-1F
<B MMA>
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D5700 ZENER D MTZJ5.1B 1 224470512T
D5701 ZENER D MTZJ5.1B 1 224470512T
D9000 DIODE 1SS133 1 223163T
D9001 DIODE 1SS133 1 223163T
D9002 DIODE 1SS133 1 223163T
D9003 DIODE 1SS133 1 223163T
D9004 DIODE 1SS133 1 223163T
D9005 DIODE 1SS133 1 223163T
D9006 DIODE 1SS133 1 223163T
D9007 ZENER D MTZJ5.1B 1 224470512T
D9008 DIODE 1SS133 1 223163T
D9009 DIODE 1SS133 1 223163T
D9101 DIODE 1SS133 1 223163T
D9200 DIODE 1SS133 1 223163T
Q5600 IC NE5532AP(TI) 1 22242274
Q5700 IC TC74HC4052AP 1 22242425
Q5800 IC NE5532AP(TI) 1 22242274
Q9101 TR 2SC1815-GR 1 2211255T
Q9200 TR 2SC1815-GR 1 2211255T
[TRANS COIL]
T9000 P TRANS NPT-1520JQ 1 2301812A
!
<B MDD>
T9000 P TRANS NPT-1520GQ 1 2301813A
!
<B MMA>
[CAPACITOR]
