Integra DHC-80.2B Service Manual

26/157 PAGE
P9006 FASTON AS FASTON_PAMC5500 1 1F999028UL <B MDD, B MMA>
P9008A PLUG NPLG-2P631 1 25055675 <B MMA>
P9100 PLUG NPLG-2P632 1 25055676
P9200 PLUG NPLG-2P632 1 25055676
P9300 PLUG NPLG-2P632 1 25055676
RL9101 RELAY NRL-1P5A-DC9-179 1 25065669
!
RL9200 RELAY NRL-1P5A-DC9-179 1 25065669
!
U0040 U0040+U0041 BAASP-0202-1Q *
1
1B234502-1Q
U0040 AUDIO IN/OUT PC BOARD AS BAASP-0202-1Q
1
1B2345202-1Q
U0041 VIDEO IN/OUT PC BOARD AS BAVD-0203-1Q
1
1B2345203-1Q
N
CIRCUIT NO.
PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
D2000 DIODE D5SBA20 1 22380130
D2000 or DIODE D5SBA60 ( 1) 22380070
D2000A HEAT SINK RAD-083 1 27160271
D2000B SCREW 3P+6FN(3BC) 1 82143006GR
D2001 C-DIODE 1SS352 1 223234R2
D2001 or C-DIODE 1SS355 ( 1) 223269R2
D2001 or C-DIODE MA2J111 ( 1) 223279R2
D2001 or C-DIODE KDS4148U ( 1) 223283R2
D2003 DIODE RB070M-30 1 22380361R2
D2004 ZENER D UDZS3.9B 1 224550390R2
D2005 DIODE RL1N4003 1 22380260T
D2006 DIODE RL1N4003 1 22380260T
D2007 DIODE RL1N4003 1 22380260T
D2008 DIODE RL1N4003 1 22380260T
D2009 ZENER D UDZS3.9B 1 224550390R2
D2010 C-DIODE 1SS352 1 223234R2
D2010 or C-DIODE 1SS355 ( 1) 223269R2
D2010 or C-DIODE MA2J111 ( 1) 223279R2
D2010 or C-DIODE KDS4148U ( 1) 223283R2
D2011 C-DIODE 1SS352 1 223234R2
D2011 or C-DIODE 1SS355 ( 1) 223269R2
D2011 or C-DIODE MA2J111 ( 1) 223279R2
D2011 or C-DIODE KDS4148U ( 1) 223283R2
